NAFSA
NAFSA - VM/ND series VM20/ND
The VM/ND series holds without power due to a permanent magnet.
Â
When the voltage is applied, the holding force is removed.
Â
Please ensure safe operating conditions are met when using this type of holding electromagnet.
Â
- Magnetic holding under no power
- Class Y winding (90ºC)
- Up to 40% duty cycle
- Up to 2254N force
- Customer specific version available
Selected variant
Technical data
| Duty cycle | 20 % |
|---|---|
| Insulation class | Y (90ºC) |
| IP class | IP65 |
| Minimum impulse time for voltage to release | 24 ms |
| Power | 10 W |
| Total weight | 40 g |
| Voltage dc max | 24 V |
| Voltage type | DC |
Downloads
Product description
The VM/ND series holds without power due to a permanent magnet.
Â
When the voltage is applied, the holding force is removed.
Â
Please ensure safe operating conditions are met when using this type of holding electromagnet.
Â
