DATALOGIC
Datalogic - Quick Link 100
Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL100/150/200 are slave modules designed for use with the master modules QL300/500 or CBX100/500. Quick Link 100 is a T-connector used in ID-NET™ networks for distributing signals and supply voltage to the reader.
- Fast, easy connection for ID-NET™ networks
- Compact dimensions
- Time-saving solution
Selected variant
Technical data
| IP class | IP65 |
|---|---|
| Power consumption max | 4 A |
| Storage temperature max | 70 °C |
| Storage temperature min | -20 °C |
| Supply voltage dc max | 30 V DC |
| Supply voltage dc min | 10 V DC |
| Temperature operational max | 50 °C |
| Temperature operational min | 0 °C |
| Weight | 115 g |
Product description
Quick Link is a complete series for fast, easy cabling of an ID-NET™ network by means of standard cables. QL100/150/200 are slave modules designed for use with the master modules QL300/500 or CBX100/500. Quick Link 100 is a T-connector used in ID-NET™ networks for distributing signals and supply voltage to the reader.
