ASCO - Flowtronic D programmable proportional valve for flow regulation
FlowtronicD, with its direct operating solenoid regulates flow with high accuracy and short response time. The regulation parameters can be easily adjusted via a PC allowing the regulator to be set optimally for each individual application. FlowtronicD can, naturally, be used without software; flow is then set using push buttons on the regulator operation panel. The regulator has auto-tune, which automatically regulates the current to the coil for optimal regulation, as well as fault indication via LEDs on the control panel. Available with or without a display.
Connection
|
Pin | Description | Cable 2 m (5 wires) | Cable 5 m (6 wires) |
1 | Supply 24 V DC | brown | brown |
2 | Analogue signal, input | white | white |
3 | Earth, supply | blue | green |
 | Earth, analogue control signal* |  | yellow |
4 | Analogue signal, output | black | pink |
5 | Digital output (pressure switch) | grey | grey |
Housing | Screening (EMC) | screen | screen |
Â
Â
- Direct operating
- Rapid and accurate pressure regulation
- Simple optimisation of regulation parameters
- LED display
Selected variant
Technical data
General Data |
|
|---|---|
| Connection | G1/4 |
| IP class | IP65 |
Material Data |
|
| Material of seals | NBR |
| Material internal parts | Aluminium, Brass, Stainless steel |
Temperature Data |
|
| Temperature of media from | 0 °C |
| Temperature of media to | 50 °C |
Additional Data |
|
|---|---|
| Pressure max | 8 bar |
| Response time | 200 ms |
| Weight | 1.85 kg |
| Power consumption | 30 W |
| Throughput | 5 mm |
| Voltage dc | 24 V |
| Temperature operational min | 0 °C |
| Temperature operational max | 40 °C |
| Flow max | 500 l/min |
| Load max | 1250 mA |
| Material of body | Aluminium |
Downloads
Product description
FlowtronicD, with its direct operating solenoid regulates flow with high accuracy and short response time. The regulation parameters can be easily adjusted via a PC allowing the regulator to be set optimally for each individual application. FlowtronicD can, naturally, be used without software; flow is then set using push buttons on the regulator operation panel. The regulator has auto-tune, which automatically regulates the current to the coil for optimal regulation, as well as fault indication via LEDs on the control panel. Available with or without a display.
Connection
|
Pin | Description | Cable 2 m (5 wires) | Cable 5 m (6 wires) |
1 | Supply 24 V DC | brown | brown |
2 | Analogue signal, input | white | white |
3 | Earth, supply | blue | green |
 | Earth, analogue control signal* |  | yellow |
4 | Analogue signal, output | black | pink |
5 | Digital output (pressure switch) | grey | grey |
Housing | Screening (EMC) | screen | screen |
Â
Â
