Flow Switches
Honsberg - UR1 Series Flow Switch
Paddle
- Switching range 1,3..35 l/min
- Water (oils, gases and aggressive media available on request)
- G⅜" up to G2"
- Brass or stainless steel wetted parts
- Max pressure 25 bar
Honsberg - UR3K Series Flow Switch
Paddle
- Swittching Range 3,5..69 l/min H₂O
- Water (oils, gases and aggressive media available on request)
- G⅜" up to G2"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 25 bar
Honsberg - UM3K Series Flow Switch
Paddle
- Switching Range 4..93 l/min H₂O
- Water (oils, gases and aggressive media available on request)
- G⅜" up to G1"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 25 bar
Honsberg - CRG Series Flow Switch
Paddle
- Switching Range 0,2...165,7 m3/h
- Water (oils and aggressive media available on request)
- Male Thread R1"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 11 bar
Honsberg - RVM Series Flow Switch
Piston
- Swittching Range 0,04..3 l/m H₂O
- Water (gas and aggressive media available on request)
- G¼"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 300 bar
Honsberg - HD1K Series Flow Switch
Piston
- Switching Range 0,1..80 l/min H₂O
- Water, Oil (gases and aggressive media available on request)
- G¼" up to G1"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
Honsberg - FF Series Flow Switch
Piston
- Switching Range 0,4..90 l/min H₂O
- Water (oils on request)
- G¼ up to G1½
- Bronze, brass, stainless steel, ferrite & NBR
- Pressue range from 16 bar up to 200 bar
Honsberg - FW1 Series Flow Switch
Piston
- Switching Range 1..11 l/min H²O
- Water (Oil available on request)
- G¼" up tp G1"
- Brass or POM Wetted Parts
- Max Pressure 10 bar
Honsberg - MR1K Series Flow Switch
Piston
- Switching Range 0,4..60 l/min H²O
- Water (oils, gases and aggressive media available on request)
- G¼ up to G1
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
Honsberg - VD Series Flow Switch
Piston
- Switching Range 1..600 l/min H²O
- Water (oils and gases available on request)
- G¼" up to G3"
- Red Bronze Wetted Parts
- Max Pressure 16 bar
Honsberg - HD2K Series Flow Switch
Piston
- Switching Range 0,5..60 l/min
- Oil
- G¼" up to G1"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
MR flow switch
- Switching Range 0,4..60 l/min H²O
- Water (oils, gases and aggressive media available on request)
- G¼ up to G1
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
