Honsberg - LABO XF Series Flow Meter XF-008GMI015
Dynamic diaphragm (flap)
Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.
- For liquids up to 16 bar
- Flow from 1 l/min. to 80 l/min.
- Connection from 1/4" to 3/4"
- Housing in PPS or stainless
Selected variant
Technical data
| Accuracy | ± 3% of the measured value, but at least 0.25 l / min |
|---|---|
| Connection type | Internal thread G ¼ " |
| Electrical connection | Plug M12x1, 4-pole |
| Flow max | 120 l/min |
| Flow range max | 15 l/min |
| Flow range min | 1 l/min |
| Function | Dynamic membrane |
| IP class | IP67 |
| Load max | 100 mA |
| Material of body | PPS |
| Material of connection | Nickel-plated brass |
| Material of seals | Viton |
| Material tinplate | Stainless steel 1.4031k |
| Power consumption | 20 mA |
|---|---|
| Pressure drop | Approximately 0.5 bar at maximum flow |
| Pressure range max | 16 bar |
| Signal outputs | 4-20 mA |
| Temperature of media from | 0 °C |
| Temperature of media to | 70 °C |
| Type of flow component | Flow Measuring |
| Viscosity max | 1 cSt |
| Voltage dc max | 30 V |
| Voltage dc min | 10 V |
| Weight | 0.35 kg |
Product description
Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.
