Molex - mPm DIN Form A low housing / high housing C28200N0R

Standard internal thread DIN valve connector, IP65 rated. Available with different thread style, gaskets and circuitry. Conforms to EN 175301-803.



IP67 rated DIN valve connectors with improved strain relief. Cable retention force increased by up to 20% over internal nut styles. Enlarged Cable range that covers the PG9 and PG11 internal thread connector cable range. Conforms to EN 175301-803.



Read more
  • With or without LED and transient protection
  • Fibreglass-reinforced housing
  • Turnable insert
  • EN175301-803 (DIN43650)-A

Selected variant

Available in several variants
molex_logo.eps

Save page as PDF

Technical data / Documents

Product description

Accessories & Related products

Selected variant

Technical data

Technical data
Number of poles 2 + earth
Circuit No circuit
IP class IP67
Cross section max 1.5 mm²
Cable diameter max 9 mm
Cable diameter min 4 mm
Housing Colour Black
Housing material Polyamide
LED indicator No
Connector DINA 43650

*Invisible Heading*
Temperature operational max 90 °C
Temperature operational min -40 °C
Current max 16 A
Rated voltage 250 V AC/300 V DC
Material packing NBR
Colour LED No LED
Screw and gasket Integrated NBR Gasket & IP67 screw
Manufacturer part no. 1212010001

Downloads

Measurements and connections

Technical illustrations

Product description

Standard internal thread DIN valve connector, IP65 rated. Available with different thread style, gaskets and circuitry. Conforms to EN 175301-803.



IP67 rated DIN valve connectors with improved strain relief. Cable retention force increased by up to 20% over internal nut styles. Enlarged Cable range that covers the PG9 and PG11 internal thread connector cable range. Conforms to EN 175301-803.



Accessories

Related products

Add product as a new cart row

You already added this product. Choose whether to increase quantity on the existing row or add the product as a new row.

Related
