Molex - mPm DIN Form B Industrial / DIN Form B
IP67 rated DIN valve connectors with improved strain relief. Cable retention force increased by up to 20% over internal nut styles. Enlarged Cable range that covers the PG9 and PG11 internal thread connector cable range. Conforms to EN 175301-803.
- With or without LED and transient protection
- Fibreglass-reinforced housing
- Turnable insert
- 11 mm or 10 mm connector distance EN175301-803 (DIN43650-B Industrial/-B)
Selected variant
Technical data
| Cable diameter max | 9 mm |
|---|---|
| Cable diameter min | 4 mm |
| Circuit | No circuit |
| Colour LED | No LED |
| Cross section max | 1.5 mm² |
| Current max | 16 A |
| Housing Colour | Black |
| Housing material | Polyamide |
| IP class | IP67 |
| LED indicator | No |
|---|---|
| Manufacturer part no. | 1212020001 |
| Material packing | NBR |
| Number of poles | 2 + earth |
| Rated voltage | 250 V AC/300 V DC |
| Screw and gasket | Integrated NBR Gasket & IP67 screw |
| Temperature operational max | 90 °C |
| Temperature operational min | -40 °C |
Product description
IP67 rated DIN valve connectors with improved strain relief. Cable retention force increased by up to 20% over internal nut styles. Enlarged Cable range that covers the PG9 and PG11 internal thread connector cable range. Conforms to EN 175301-803.
