FLEXA
RQG straight, quick-type, metric
RQG and RQG1 connectors are made of polyamide. They are highly resistant against oil, various acids and solvents. Halogen-free.
Â
RQG is rated IP68, RQG1 IP66.
- Metric or PG thread
- Straight
- RQG IP 68/ IP 69K
- RQG1 IP 66
Selected variant
Technical data
| Approvals | CPT, cRUus, Lloyd´s, REACH, RoHS, VDE |
|---|---|
| Colour | Black |
| Hose dimension AD | 10 |
| IP class | IP66 |
| Material | Polyamide |
| Pack size | 50 Â |
| Temperature operational max | 120 °C |
| Temperature operational min | -40 °C |
| Thread | M10 |
Product description
RQG and RQG1 connectors are made of polyamide. They are highly resistant against oil, various acids and solvents. Halogen-free.
Â
RQG is rated IP68, RQG1 IP66.
