Datasensing SH4-Base Finger Protection Safety Light Curtain
Datasensing's SH4-BASE is a simple safety light curtain. All you need is a supply voltage for the emitter and receiver and from the receiver you get your safety outputs. (2 x OSSD)
Â
The finger protection resolution is 14mm and the maximum distance between the emitter and receiver is 10m.
Â
SH4 Safety light curtains do not have a dead zone, they detect throughout the entire length of the light curtain.
- Finger protection (R14), range 0.2-10 m
- Controlled height 300-2250mm
- Temperature Range from -30 to +55 °C
- 2 x OSSD safety outputs
Selected variant
Technical data
| Function | Automatic restart |
|---|---|
| Material of body | Aluminium |
| MTTFd | 43 year(s) |
| Number of beams | 30 |
| PL | e |
| Protection height | 300 mm |
| Reaction time | 9 ms |
| Resolution | 14 mm |
| Sensing distance | 0,2-10 m |
|---|---|
| SIL | 3 |
| Supply voltage | 24 V DC |
| Temperature operational max | 55 °C |
| Temperature operational min | -30 °C |
| Voltage tolerance | ± 20% |
Product description
Datasensing's SH4-BASE is a simple safety light curtain. All you need is a supply voltage for the emitter and receiver and from the receiver you get your safety outputs. (2 x OSSD)
Â
The finger protection resolution is 14mm and the maximum distance between the emitter and receiver is 10m.
Â
SH4 Safety light curtains do not have a dead zone, they detect throughout the entire length of the light curtain.
