Datasensing SH4-Advanced Finger Protection Safety Light Curtain
The Datasensing SH4-Advanced safety light curtain is fully programmable via Wi-Fi, with the SH4-designer program. Programmable fuctions include partial muting, dynamic muting, 4-signal muting, and versatile blanking functions.
- Finger protection (R14), range 0.2-10 m
- Protection height 300-2250mm
- Temperature Range from -30 to +55 °C
- Versatile muting functions programmable via wi-fi
Selected variant
Technical data
| Function | Muting, Blanking, EDM, Manual/automatic restart |
|---|---|
| Material of body | Aluminium |
| MTTFd | 43 year(s) |
| Number of beams | 30 |
| PL | e |
| Protection height | 300 mm |
| Reaction time | 9 ms |
| Resolution | 14 mm |
| Sensing distance | 0,2-10 m |
|---|---|
| SIL | 3 |
| Supply voltage | 24 V DC |
| Temperature operational max | 55 °C |
| Temperature operational min | -30 °C |
| Voltage tolerance | ± 20% |
Product description
The Datasensing SH4-Advanced safety light curtain is fully programmable via Wi-Fi, with the SH4-designer program. Programmable fuctions include partial muting, dynamic muting, 4-signal muting, and versatile blanking functions.
