Selected variant
Technical data
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| 2D Code Types | Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code |
| Approvals | RoHS |
| Colour | Black / black |
| Dimension (mm) | 47 x 27 x 38 |
| Drop resistance | Withstands repeated drops from 3 ft onto a concrete surface |
| Humidity | 5 - 95% (Non-condensing) |
| Immunity to ambient light | 0 - 100,000 lux |
| Interface | USB |
| IP class | IP54 |
| Light source | Illumination: White LEDs |
| Output current | 214 mA |
| Postal Code Types | China Post, IMB, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), Australia Postal, Japan Postal, Korea Post |
|---|---|
| Readable code types | 1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes |
| Reading angle window | Pitch:+/-60°; Tilt: +/- 180°; Skew: +/-60° |
| Resolution | 7.5 mils |
| Sensor Type | Wide VGA: 752 x 480 pixels |
| Stacked Code Types | EAN/JAN Composites, GS1 Databar Composites, GS1 Databar Expanded Stacked, GS1 Databar Stacked, GS1 Databar Stacked Omnidirectional, Macro PDF, Micro PDF 417, PDF 417, UPC A/E Composites |
| Storage temperature max | 70 °C |
| Storage temperature min | -40 °C |
| Temperature operational max | 50 °C |
| Temperature operational min | -20 °C |
| Weight | 131 g |
