Selected variant
Technical data
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| Approvals | RoHS |
| Dimension (mm) | 11.4 x 21 x 15.2 |
| Humidity | 5 - 95% (Non-condensing) |
| Immunity to ambient light | 0 - 100,000 lux |
| Interface | Undecoded |
| Light source | Illumination: Green LED |
| Output current | <160 mA |
| Readable code types | 1D / Linear Codes |
| Reading angle window | Pitch:+/-75°; Tilt: +/- 45°; Skew: +/-70° |
|---|---|
| Resolution | 0.0762 mm / 2.5 mils |
| Storage temperature max | 70 °C |
| Storage temperature min | -40 °C |
| Temperature operational max | 60 °C |
| Temperature operational min | -30 °C |
| Weight | 9 g |
