Selected variant
Technical data
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| 2D Code Types | Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Aztec Mesas |
| Approvals | RoHS |
| Battery | Lithium-ion 700 mAh |
| Charge time | 2.5 hrs |
| Colour | Black |
| Dimension (mm) | 112.5 x 42.3 x 27.5 |
| Drop resistance | Withstands repeated drops from 5ft onto a concrete surface |
| Humidity | 5-95% (Non-condensing) |
| Immunity to ambient light | 0-100,000 lux |
| Interface | USB COM, USB-OEM, USB keyboard wedge |
| IP class | IP50 |
| Kit | No |
| Light source | White |
| Postal Code Types | China Post, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), UK Postal, Australia Postal, Japan Postal, Canadian Post, Korea Post |
| Readable code types | 1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes |
|---|---|
| Reading angle window | Pitch:+/-65°; Tilt: up to 360°; Skew: +/-60° |
| Reads per charge | 3000 |
| Resolution | 4 mil |
| Sensor Type | Wide VGA: 752 x 480 pixels |
| Stacked Code Types | EAN/JAN Composites, GS1 Databar Composites, GS1 Databar Expanded Stacked, GS1 Databar Stacked, GS1 Databar Stacked Omnidirectional, Macro PDF, Micro PDF 417, PDF 417, UPC A/E Composites |
| Storage temperature max | 70 °C |
| Storage temperature min | -20 °C |
| Temperature operational max | 50 °C |
| Temperature operational min | 0 °C |
| Weight | 85 g |
| Wireless | Yes |
| Wireless technology | Bluetooth Wireless Technology |
