Selected variant
Technical data
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| 2D Code Types | Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Aztec Mesas |
| Approvals | RoHS |
| Colour | Black |
| Dimension (mm) | 163 x 91 x 41 |
| Drop resistance | Withstands repeated drops from 5ft onto concrete surface |
| Humidity | 0-95% (Non-condensing) |
| Immunity to ambient light | 86,000 lux |
| Interface | Keyboard wedge, OEM (IBM) USB, RS-232, USB |
| IP class | IP42 |
| Kit | No |
| Light source | Red LED 610-650nm |
| Output current | 400mA @ 5VDC |
| Postal Code Types | China Post, IMB, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC), UK Postal, Australia Postal, Japan Postal, Canadian Post |
|---|---|
| Readable code types | 1D / Linear Codes, 2D Codes, Postal Codes, Stacked Codes |
| Reading angle window | Pitch:+/-65°; Tilt: +/- 360°; Skew: +/-60° |
| Sensor Type | Wide VGA: 752 x 480 pixels |
| Stacked Code Types | EAN/JAN Composites, GS1 Databar Composites, GS1 Databar Expanded Stacked, GS1 Databar Stacked, GS1 Databar Stacked Omnidirectional, Macro PDF, Micro PDF 417, PDF 417, UPC A/E Composites |
| Storage temperature max | 70 °C |
| Storage temperature min | -40 °C |
| Temperature operational max | 50 °C |
| Temperature operational min | 0 °C |
| Weight | 145 g |
| Wireless | No |
