Selected variant
Technical data
| 1D Code types | Auto discriminates all standard 1D codes |
|---|---|
| Approvals | RoHS |
| Colour | Black |
| Dimension (mm) | 163 x 91 x 41 |
| Drop resistance | Withstands repeated drops from 5ft onto concrete surface |
| Humidity | 90% (Non-condensing) |
| Immunity to ambient light | 0 - 120,000 lux |
| Interface | Keyboard wedge, OEM (IBM) USB, RS-232, USB |
| IP class | IP42 |
| Kit | No |
| Light source | Red LED 610-650 nm |
| Output current | 400mA @ 5VDC |
| Readable code types | 1D / Linear Codes |
|---|---|
| Reading angle window | Pitch:+/-65°; Tilt: +/- 45°; Skew: +/-70° |
| Reading speed | 400 reads/sec |
| Resolution | 0.102mm / 4 mils |
| Storage temperature max | 70 °C |
| Storage temperature min | -40 °C |
| Temperature operational max | 50 °C |
| Temperature operational min | 0 °C |
| Weight | 150 g |
| Wireless | No |
