Connection | G1/2 |
---|---|
Electrical connection | DIN EN 175301-803-A |
IP class | IP65 |
Length | 50 mm |
Manufacturer part no. | PT25/PD/50/6/G1/2"/0..+50C/NR |
Material of body | Stainless steel AISI 304 |
Material of wetted parts | Stainless steel 316L |
Signal type | 4-20 mA |
---|---|
Supply voltage dc max | 35 V DC |
Supply voltage dc min | 8 V DC |
Temperature operational max | 50 °C |
Temperature operational min | 0 °C |
Pumps are now officially part of our product offering! As we build our pump portfolio, we’re proud to announce that we are an official distributor of SAMOA Industrial, a well-established name in the fluid handling industry.
This blog post demonstrates 7 strong reasons production plants choose the HYGHSPIN twin screw pump by Jung Process Systems
When selecting a SUCO mechanical pressure switch, it's essential to consider several key factors...
When it comes to solenoid valves, reliability and ease of maintenance are essential. That’s why our new Emerson, high flow solenoid valve is designed with unique features that streamline testing, commissioning, and ongoing operation.Â
Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.
Did you know that OEM Automatic has been successfully providing valve actuation solutions?
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Electrical connection | IP class | Length | Manufacturer part no. | Temperature operational max | Price | ||
---|---|---|---|---|---|---|---|---|
![]()
0..50°C 4-20mA 6x50mm G1/2" DIN-A
Art:
PT25050050.000
Copied
|
DIN EN 175301-803-A
|
IP65
|
50 mm
|
PT25/PD/50/6/G1/2"/0..+50C/NR
|
50 °C
|
| ||
![]()
0..50°C 4-20mA 6x50mm G1/2" M12-connector
Art:
PT25050050.001
Copied
|
M12x1 4-pole
|
IP67
|
50 mm
|
PT25/PM12/50/6/G1/2"/0..+50C/NR
|
50 °C
|
| ||
![]()
0..100°C 4-20mA 6x75mm G1/2" DIN-A
Art:
PT25100075.000
Copied
|
DIN EN 175301-803-A
|
IP65
|
75 mm
|
PT25/PD/75/6/G1/2"/0..+100C/NR
|
100 °C
|
|
Select a variant in the list
