ASCO

ASCO - 2/2 Proportional valve M5

Normally closed
Compact version
Working pressure 0 to 12 bar
Housing in brass

Selected variant

Save page as PDF

Technical data / Documents

Accessories & Related products

Selected variant

Technical data

Material Data
Material body	Brass

Temperature Data
Temperature of media from	0 °C
Temperature of media to	60 °C
Throughput	0.8 mm
Differential air pressure max	12 bar
Differential pressure max	12 bar
Differential pressure min	0 bar
Differential pressure vacuum max	1 bar
Flow max	0.3 l/min
Function 1	2/2
Function 2	Normally Closed

Downloads

SCG202 M5-18.pdf

Accessories

	Parts	Connection	Throughput	Differential air pressure max	Differential pressure max	Flow max	Price
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A101VS3 Copied		0.8 mm	12 bar	12 bar	0.3 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A102VS3 Copied		1.2 mm	7 bar	7 bar	0.8 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A103VS3 Copied		1.6 mm	4 bar	4 bar	1.3 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A104VS3 Copied		2 mm	2.5 bar	2.5 bar	1.7 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A105VS3 Copied	M5	0.8 mm	12 bar	12 bar	0.3 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A106VS3 Copied	M5	1.2 mm	7 bar	7 bar	0.8 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A107VS3 Copied	M5	1.6 mm	4 bar	4 bar	1.3 l/min
	Proportional Valve 2/2 NC. M5, 24VDC Art: SCS202A108VS3 Copied	M5	2 mm	2.5 bar	2.5 bar	1.7 l/min
