General Data |
|
|---|---|
| Connection | 3/8 BSP |
| Flow factor / flow coefficient | 2,1 |
| IP class | IP65 |
Material Data |
|
| Material body | Brass |
Temperature Data |
|
| Temperature of media from | -10 °C |
| Temperature of media to | 90 °C |
Additional Data |
|
|---|---|
| Pressure max | 15 bar |
| Viscosity max | 40 cSt |
| Weight | 0.65 kg |
| Power consumption | 8 W |
| Throughput | 12.5 mm |
| Sensitivity | <2 % |
| Voltage dc | 24 V |
| Temperature operational min | -20 °C |
| Temperature operational max | 75 °C |
| Material coil | Epoxy |
| Differential pressure max | 10 bar |
| Differential pressure min | 0.3 bar |
| Flow max | 35 l/min |
| Function 1 | 2/2 |
| Function 2 | Normally Closed |
| Material plunger | Stainless steel |
| Material glide ring | PTFE |
| Material seat seal | FPM |
| Material spring | Stainless steel |
| Material membrane | NBR |
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Connection | Weight | Price | ||
|---|---|---|---|---|---|
Proportional valve 2/2 NC 3/8" 24VDC
Art:
SCG203B001S3
Copied
|
3/8 BSP
|
0.65 kg
|
| ||
|
Proportional valve 2/2 NC 1/2 24VDC
Art:
SCG203B002S3
Copied
|
1/2 BSP
|
0.6 kg
|
|
Select a variant in the list
