Selected variant
Technical data
General Data |
|
|---|---|
| Connection | 3/8 BSP |
| IP class | IP65 |
Material Data |
|
| Material body | Brass |
| Material of seals | EPDM |
| Material seat | Brass |
Temperature Data |
|
| Temperature of media from | -20 °C |
| Temperature of media to | 184 °C |
Additional Data |
|
|---|---|
| Pressure max | 10 bar |
| Close delay | 40 ms |
| Power consumption | 10.5 W |
| Throughput | 16 mm |
| Type of valve | Solenoid valve |
| Response time off | 120 ms |
| Voltage AC | 230 V |
| Temperature operational min | -20 °C |
| Temperature operational max | 40 °C |
| Material coil | Epoxy |
| Differential air pressure max | 10 bar |
| Differential pressure max | 10 bar |
| Differential pressure min | 0.35 bar |
| Differential water pressure max | 10 bar |
| Flow max | 43 l/min |
| Function 1 | 2/2 |
| Function 2 | Normally Closed (SPST) |
| Material plunger | Stainless steel |
| Material short-circuit ring | Copper |
| Material seat seal | PTFE |
| Material spring | Stainless steel |
