Emerson ASCO Solenoid Valve Series 256 Brass

Direct Acting

Emerson ASCO's 256 Brass Solenoid Valves are direct-acting 2/2 valves available in normally closed or open configurations. They come in G1/8", G1/4", 1/8" NPT, and 1/4" NPT port sizes and offer a wide range of seal options including FPM, EPDM, NBR, RUBY, and HNBR. Designed to shut off both liquid and gaseous fluids, these valves support operating pressure differentials of up to 30 bar and feature IP67-rated protection.
  • 2/2 Normally Closed or Open G1/8", G1/4", 1/8" NPT, 1/4" NPT
  • FPM, EPDM, NBR, RUBY & HNBR Seals Available
  • Suitable To Shut Off Liquid & Gasesous Fluids
  • Operating Pressure Differential: Up to 30 Bar
  • IP67

Selected variant

Available in several variants
ASCO_produktniva.tif

Save page as PDF

Technical data / Documents

Product description

Accessories & Related products

Selected variant

Technical data

General Data
Function 2/2, Normally Closed
Connection G1/8
Electrical connection DIN 46350 - 3 pole plug connector
Operating Pressure Differential 0-20 bar
Flow factor / flow coefficient 0,051
Voltage / Frequency 24 VDC
IP class IP67

Material Data
Material body Brass
Material of seals FPM
Material seat Brass
Material of core tube Stainless steel
Material internal parts Brass, Stainless steel, Copper
Encapsulation material thermoplastic

Temperature Data
Temperature ambient from -10 °C
Temperature ambient to 60 °C
Temperature of media from 0 °C
Temperature of media to 130 °C

Additional Data
Power consumption 3.5 W
Response time 20 ms
Viscosity max 40 cSt
Insulation class F (155°C) pending H (180°C)
Weight 0.116 kg
Throughput 1.2 mm
Flow max 0.85 l/min
Manual operation No

Downloads

Product description

Emerson ASCO's 256 Series Brass Solenoid Valves are compact, direct-acting 2/2 valves, available in both normally closed and normally open configurations. With a range of port sizes including G1/8", G1/4", 1/8" NPT, and 1/4" NPT, they offer flexible integration into various system designs. The availability of multiple seal materials—FPM, EPDM, NBR, RUBY, and HNBR—makes them adaptable to a wide variety of fluid types and temperatures. These valves are ideal for precise control in demanding applications, offering high performance in industries such as automotive, HVAC, packaging, food and beverage, and water treatment.

Designed to shut off both liquid and gaseous fluids, the 256 Series operates efficiently with pressure differentials up to 30 bar. Its robust brass construction and IP67-rated protection ensure durability and resistance to environmental factors like dust and water ingress, making it suitable for use in harsh industrial environments. With a compact footprint and standard manual override, the valve supports easy installation and maintenance, helping to maximise uptime in critical applications.

Accessories

Related

Tecnoplastic float switch
Product news

Float switches built to perform and ready to ship

Whether you're looking to upgrade your current solution or secure a more robust float switch for your next project, Taurus delivers performance you can count on.

SAMOA pumps
Product news

We offer air diaphragm pumps by SAMOA

Pumps are now officially part of our product offering! As we build our pump portfolio, we’re proud to announce that we are an official distributor of SAMOA Industrial, a well-established name in the fluid handling industry.

jungs process systems hyghspin
Blog Learning hub

7 advantages of using HYGHSPIN twin screw pumps

This blog post demonstrates 7 strong reasons production plants choose the HYGHSPIN twin screw pump by Jung Process Systems

suco pressure switches
Blog Learning hub

Select the pressure switch for you a step by step guide

When selecting a SUCO mechanical pressure switch, it's essential to consider several key factors...

emerson 327c
Product news Blog

Function test without opening the enclosure Emerson 327c

When it comes to solenoid valves, reliability and ease of maintenance are essential. That’s why our new Emerson, high flow solenoid valve is designed with unique features that streamline testing, commissioning, and ongoing operation.

IATECH, the industrial automation technology exhibition OEM automatic
Company news

Recap of IATECH

Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.

Parts Function Connection Operating Pressure Differential Flow factor / flow coefficient Voltage / Frequency Material of seals Material seat Temperature of media from Temperature of media to Power consumption Response time Weight Throughput Flow max Manual operation Price
256 Brass.jpg
2/2 N.C., G1/8", 0-20 bar, 0.051, FPM, 24VDC, IP67
Art:
G256C134S1V00F1 Copied
2/2, Normally Closed
G1/8
0-20 bar
0,051
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-20 bar, 0.051, FPM, 24VDC, IP67
Art:
G256C134S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-20 bar
0,051
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, FPM, 230V/50Hz, IP67
Art:
G256C134S1V00FH Copied
2/2, Normally Closed
G1/8
0-30 bar
0,051
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, FPM, 230V/50Hz, IP67
Art:
G256C134S1V01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0,051
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-26 bar, 0.051, FPM, 24VDC, IP67
Art:
G256C149S1V00F1 Copied
2/2, Normally Closed
G1/8
0-26 bar
0,051
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-26 bar, 0.051, FPM, 24VDC, IP67
Art:
G256C149S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-26 bar
0,051
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-12 bar, 0.08, FPM, 24VDC, IP67
Art:
G256C135S1V00F1 Copied
2/2, Normally Closed
G1/8
0-12 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-12 bar, 0.08, FPM, 24VDC, IP67
Art:
G256C135S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-12 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, FPM, 230V/50Hz, IP67
Art:
G256C135S1V00FH Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, FPM, 230V/50Hz, IP67
Art:
G256C135S1V01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-16 bar, 0.08, FPM, 24VDC, IP67
Art:
G256C150S1V00F1 Copied
2/2, Normally Closed
G1/8
0-16 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-16 bar, 0.08, FPM, 24VDC, IP67
Art:
G256C150S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-16 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.12, FPM, 24VDC, IP67
Art:
G256C136S1V00F1 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.12
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.12, FPM, 24VDC, IP67
Art:
G256C136S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.12
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, FPM, 230V/50Hz, IP67
Art:
G256C136S1V00FH Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, FPM, 230V/50Hz, IP67
Art:
G256C136S1V01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.11, FPM, 24VDC, IP67
Art:
G256C151S1V00F1 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.11
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.11, FPM, 24VDC, IP67
Art:
G256C151S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.11
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-4 bar, 0.14, FPM, 24VDC, IP67
Art:
G256C137S1V00F1 Copied
2/2, Normally Closed
G1/8
0-4 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-4 bar, 0.14, FPM, 24VDC, IP67
Art:
G256C137S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-4 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, FPM, 230V/50Hz, IP67
Art:
G256C137S1V00FH Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, FPM, 230V/50Hz, IP67
Art:
G256C137S1V01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-13 bar
0.14
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.14, FPM, 24VDC, IP67
Art:
G256C152S1V00F1 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.14, FPM, 24VDC, IP67
Art:
G256C152S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-2 bar, 0.18, FPM, 24VDC, IP67
Art:
G256C138S1V00F1 Copied
2/2, Normally Closed
G1/8
0-2 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-2 bar, 0.18, FPM, 24VDC, IP67
Art:
G256C138S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-2 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, FPM, 230V/50Hz, IP67
Art:
G256C138S1V00FH Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, FPM, 230V/50Hz, IP67
Art:
G256C138S1V01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/8", 0-3 bar, 0.18, FPM, 24VDC, IP67
Art:
G256C153S1V00F1 Copied
2/2, Normally Closed
G1/8
0-3 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-3 bar, 0.18, FPM, 24VDC, IP67
Art:
G256C153S1V01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-3 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
Yes
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 24VDC, IP67,
Art:
G256C102S1V00F1 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 230V/50Hz, IP67,
Art:
G256C102S1V00FH Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
230V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 24VDC, IP67,
Art:
G256C119S1V00F1 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, FPM, 24VDC, IP67,
Art:
G256C121S1V00F1 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, FPM, 230V/50Hz, IP67,
Art:
G256C121S1V00FH Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-18 bar, 0.18, FPM, 24VDC, IP67,
Art:
G256C104S1V00F1 Copied
2/2, Normally Closed
G1/4
0-18 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.3, FPM, 24VDC, IP67,
Art:
G256C106S1V00F1 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.3
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.4, FPM, 24VDC, IP67,
Art:
G256C124S1V00F1 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.4
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, FPM, 230V/50Hz, IP67,
Art:
G256C124S1V00FH Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-3 bar, 0.4, FPM, 24VDC, IP67,
Art:
G256C107S1V00F1 Copied
2/2, Normally Closed
G1/4
0-3 bar
0.4
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-4 bar, 0.48, FPM, 24VDC, IP67,
Art:
G256C125S1V00F1 Copied
2/2, Normally Closed
G1/4
0-4 bar
0.48
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, FPM, 230V/50Hz, IP67,
Art:
G256C125S1V00FH Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-2 bar, 0.48, FPM, 24VDC, IP67,
Art:
G256C108S1V00F1 Copied
2/2, Normally Closed
G1/4
0-2 bar
0.48
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
No
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, FPM, 230V/50Hz, IP67
Art:
G256C230S1V00FH Copied
2/2, Normally open
G1/8
0-17 bar
0.05
230V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
No
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, FPM, 24VDC, IP67
Art:
G256C246S1V00F1 Copied
Normally open, 2/2
G1/8
0-17 bar
0.05
24 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
No
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, FPM, 230V/50Hz, IP67
Art:
G256C231S1V00FH Copied
2/2, Normally open
G1/8
0-17 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
No
256 Brass.jpg
2/2 N.O., G1/8", 0-10 bar, 0.08, FPM, 24VDC, IP67
Art:
G256C247S1V00F1 Copied
2/2, Normally open
G1/8
0-10 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.2 kg
1.6 mm
1.33 l/min
No
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24VDC, IP67
Art:
G256C216S19DQF1 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24 VDC
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
No
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.4, EPDM, 24VDC, IP67,
Art:
G256C124S1E00F1 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.4
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 110V/50Hz, IP67,
Art:
8256C102S1E00F0 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 24VDC, IP67,
Art:
8256C102S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 12VDC, IP67,
Art:
8256C102S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 230V/50Hz, IP67,
Art:
8256C102S1E00FH Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
230V/50Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 24/50Hz, IP67,
Art:
8256C102S1E00FQ Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24V/50Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 110V/50Hz, IP67,
Art:
8256C102S1V00F0 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
110V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 24VDC, IP67,
Art:
8256C102S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 12VDC, IP67,
Art:
8256C102S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 230V/50Hz, IP67,
Art:
8256C102S1V00FH Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
230V / 50Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 24/50Hz, IP67,
Art:
8256C102S1V00FQ Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-18 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C104S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-18 bar
0.18
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-18 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C104S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-18 bar
0.18
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-18 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C104S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-18 bar
0.18
24 VDC
EPDM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-18 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C104S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-18 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.3, EPDM, 24VDC, IP67,
Art:
8256C106S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.3
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.3, EPDM, 12VDC, IP67,
Art:
8256C106S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.3
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.3, FPM, 24VDC, IP67,
Art:
8256C106S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.3
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.3, FPM, 12VDC, IP67,
Art:
8256C106S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.3
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-3 bar, 0.4, EPDM, 24VDC, IP67,
Art:
8256C107S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-3 bar
0.4
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-3 bar, 0.4, EPDM, 12VDC, IP67,
Art:
8256C107S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-3 bar
0.4
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-3 bar, 0.4, FPM, 24VDC, IP67,
Art:
8256C107S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-3 bar
0.4
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-3 bar, 0.4, FPM, 12VDC, IP67,
Art:
8256C107S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-3 bar
0.4
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-2 bar, 0.48, EPDM, 24VDC, IP67,
Art:
8256C108S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-2 bar
0.48
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-2 bar, 0.48, EPDM, 12VDC, IP67,
Art:
8256C108S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-2 bar
0.48
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-2 bar, 0.48, FPM, 24VDC, IP67,
Art:
8256C108S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-2 bar
0.48
24 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-2 bar, 0.48, FPM, 12VDC, IP67,
Art:
8256C108S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-2 bar
0.48
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 24VDC, IP67,
Art:
8256C119S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, EPDM, 12VDC, IP67,
Art:
8256C119S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
12VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 24VDC, IP67,
Art:
8256C119S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-30 bar, 0.1, FPM, 12VDC, IP67,
Art:
8256C119S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-30 bar
0.1
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
8256C121S1E00F0 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C121S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
24VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C121S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
12VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
8256C121S1E00FH Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
230V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
8256C121S1E00FQ Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
24V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
8256C121S1V00F0 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C121S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C121S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, FPM, 230V/50Hz, IP67,
Art:
8256C121S1V00FH Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-20 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
8256C121S1V00FQ Copied
2/2, Normally Closed
1/4 NPT
0-20 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, EPDM, 110V/50Hz, IP67,
Art:
8256C123S1E00F0 Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-12 bar, 0.3, EPDM, 24VDC, IP67,
Art:
8256C123S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-12 bar
0.3
24VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-12 bar, 0.3, EPDM, 12VDC, IP67,
Art:
8256C123S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-12 bar
0.3
12VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, EPDM, 230V/50Hz, IP67,
Art:
8256C123S1E00FH Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
230V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, EPDM, 24/50Hz, IP67,
Art:
8256C123S1E00FQ Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
24V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, FPM, 110V/50Hz, IP67,
Art:
8256C123S1V00F0 Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-12 bar, 0.3, FPM, 24VDC, IP67,
Art:
8256C123S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-12 bar
0.3
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-12 bar, 0.3, FPM, 12VDC, IP67,
Art:
8256C123S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-12 bar
0.3
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, FPM, 230V/50Hz, IP67,
Art:
8256C123S1V00FH Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-15 bar, 0.3, FPM, 24/50Hz, IP67,
Art:
8256C123S1V00FQ Copied
2/2, Normally Closed
1/4 NPT
0-15 bar
0.3
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, EPDM, 110V/50Hz, IP67,
Art:
8256C124S1E00F0 Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.4, EPDM, 24VDC, IP67,
Art:
8256C124S1E00F1 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.4
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.4, EPDM, 12VDC, IP67,
Art:
8256C124S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.4
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, EPDM, 230V/50Hz, IP67,
Art:
8256C124S1E00FH Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
230V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, EPDM, 24/50Hz, IP67,
Art:
8256C124S1E00FQ Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
24V/50Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, FPM, 110V/50Hz, IP67,
Art:
8256C124S1V00F0 Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.4, FPM, 24VDC, IP67,
Art:
8256C124S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.4
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-6 bar, 0.4, FPM, 12VDC, IP67,
Art:
8256C124S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-6 bar
0.4
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, FPM, 230V/50Hz, IP67,
Art:
8256C124S1V00FH Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-8 bar, 0.4, FPM, 24/50Hz, IP67,
Art:
8256C124S1V00FQ Copied
2/2, Normally Closed
1/4 NPT
0-8 bar
0.4
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, EPDM, 110V/50Hz, IP67,
Art:
8256C125S1E00F0 Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-4 bar, 0.48, EPDM, 24VDC, IP67,
Art:
8256C125S1E00F1 Copied
2/2, Normally Closed, 3/2-5/2
1/4 NPT
0-4 bar
0.48
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-4 bar, 0.48, EPDM, 12VDC, IP67,
Art:
8256C125S1E00F3 Copied
2/2, Normally Closed
1/4 NPT
0-4 bar
0.48
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, EPDM, 230V/50Hz, IP67,
Art:
8256C125S1E00FH Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, EPDM, 24/50Hz, IP67,
Art:
8256C125S1E00FQ Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, FPM, 110V/50Hz, IP67,
Art:
8256C125S1V00F0 Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-4 bar, 0.48, FPM, 24VDC, IP67,
Art:
8256C125S1V00F1 Copied
2/2, Normally Closed
1/4 NPT
0-4 bar
0.48
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-4 bar, 0.48, FPM, 12VDC, IP67,
Art:
8256C125S1V00F3 Copied
2/2, Normally Closed
1/4 NPT
0-4 bar
0.48
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, FPM, 230V/50Hz, IP67,
Art:
8256C125S1V00FH Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
230V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/4" NPT, 0-5 bar, 0.48, FPM, 24/50Hz, IP67,
Art:
8256C125S1V00FQ Copied
2/2, Normally Closed
1/4 NPT
0-5 bar
0.48
24V / 50Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, EPDM, 110V/50Hz, IP67,
Art:
8256C134S1E00F0 Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-20 bar, 0.051, EPDM, 24VDC, IP67,
Art:
8256C134S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-20 bar
0.051
24 VDC
FPM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-20 bar, 0.051, EPDM, 12VDC, IP67,
Art:
8256C134S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-20 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, EPDM, 230V/50Hz, IP67,
Art:
8256C134S1E00FH Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
230V / 50 Hz
FPM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, EPDM, 24/50Hz, IP67,
Art:
8256C134S1E00FQ Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
24V / 50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, EPDM, 110V/50Hz, IP67,
Art:
8256C134S1E01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-20 bar, 0.051, EPDM, 24VDC, IP67,
Art:
8256C134S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-20 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-20 bar, 0.051, EPDM, 12VDC, IP67,
Art:
8256C134S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-20 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, EPDM, 230V/50Hz, IP67,
Art:
8256C134S1E01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, EPDM, 24/50Hz, IP67,
Art:
8256C134S1E01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, FPM, 110V/50Hz, IP67,
Art:
8256C134S1V00F0 Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-20 bar, 0.051, FPM, 24VDC, IP67,
Art:
8256C134S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-20 bar
0.051
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-20 bar, 0.051, FPM, 12VDC, IP67,
Art:
8256C134S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-20 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, FPM, 230V/50Hz, IP67,
Art:
8256C134S1V00FH Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.051, FPM, 24/50Hz, IP67,
Art:
8256C134S1V00FQ Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.051
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, FPM, 110V/50Hz, IP67,
Art:
8256C134S1V01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-20 bar, 0.051, FPM, 24VDC, IP67,
Art:
8256C134S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-20 bar
0.051
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-20 bar, 0.051, FPM, 12VDC, IP67,
Art:
8256C134S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-20 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, FPM, 230V/50Hz, IP67,
Art:
8256C134S1V01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.051, FPM, 24/50Hz, IP67,
Art:
8256C134S1V01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.051
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
8256C135S1E00F0 Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-12 bar, 0.08, EPDM, 24VDC, IP67,
Art:
8256C135S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-12 bar
0.08
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-12 bar, 0.08, EPDM, 12VDC, IP67,
Art:
8256C135S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-12 bar
0.08
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
8256C135S1E00FH Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
8256C135S1E00FQ Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
24V/50Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
8256C135S1E01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.08
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-12 bar, 0.08, EPDM, 24VDC, IP67,
Art:
8256C135S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-12 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-12 bar, 0.08, EPDM, 12VDC, IP67,
Art:
8256C135S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-12 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
8256C135S1E01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
8256C135S1E01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
8256C135S1V00F0 Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
110V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-12 bar, 0.08, FPM, 24VDC, IP67,
Art:
8256C135S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-12 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-12 bar, 0.08, FPM, 12VDC, IP67,
Art:
8256C135S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-12 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, FPM, 230V/50Hz, IP67,
Art:
8256C135S1V00FH Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-30 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
8256C135S1V00FQ Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
8256C135S1V01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.08
110V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-12 bar, 0.08, FPM, 24VDC, IP67,
Art:
8256C135S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-12 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-12 bar, 0.08, FPM, 12VDC, IP67,
Art:
8256C135S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-12 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, FPM, 230V/50Hz, IP67,
Art:
8256C135S1V01FH Copied
2/2, Normally Closed
1/8 NPT
0-30 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-30 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
8256C135S1V01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-30 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, EPDM, 110V/50Hz, IP67,
Art:
8256C136S1E00F0 Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.12, EPDM, 24VDC, IP67,
Art:
8256C136S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.12
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.12, EPDM, 12VDC, IP67,
Art:
8256C136S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.12
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, EPDM, 230V/50Hz, IP67,
Art:
8256C136S1E00FH Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, EPDM, 24/50Hz, IP67,
Art:
8256C136S1E00FQ Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, EPDM, 110V/50Hz, IP67,
Art:
8256C136S1E01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-15 bar
0.12
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.12, EPDM, 24VDC, IP67,
Art:
8256C136S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.12
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.12, EPDM, 12VDC, IP67,
Art:
8256C136S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.12
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, EPDM, 230V/50Hz, IP67,
Art:
8256C136S1E01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-15 bar
0.12
230V / 50 Hz
FPM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, EPDM, 24/50Hz, IP67,
Art:
8256C136S1E01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-15 bar
0.12
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, FPM, 110V/50Hz, IP67,
Art:
8256C136S1V00F0 Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
110V / 50 Hz
FPM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.12, FPM, 24VDC, IP67,
Art:
8256C136S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.12
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.12, FPM, 12VDC, IP67,
Art:
8256C136S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.12
12 VDC
FPM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, FPM, 230V/50Hz, IP67,
Art:
8256C136S1V00FH Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-15 bar, 0.12, FPM, 24/50Hz, IP67,
Art:
8256C136S1V00FQ Copied
2/2, Normally Closed
1/8 NPT
0-15 bar
0.12
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, FPM, 110V/50Hz, IP67,
Art:
8256C136S1V01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-15 bar
0.12
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.12, FPM, 24VDC, IP67,
Art:
8256C136S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.12
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.12, FPM, 12VDC, IP67,
Art:
8256C136S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.12
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, FPM, 230V/50Hz, IP67,
Art:
8256C136S1V01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-12 bar
0.12
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-15 bar, 0.12, FPM, 24/50Hz, IP67,
Art:
8256C136S1V01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-15 bar
0.12
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, EPDM, 110V/50Hz, IP67,
Art:
8256C137S1E00F0 Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-4 bar, 0.14, EPDM, 24VDC, IP67,
Art:
8256C137S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-4 bar
0.14
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-4 bar, 0.14, EPDM, 12VDC, IP67,
Art:
8256C137S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-4 bar
0.14
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, EPDM, 230V/50Hz, IP67,
Art:
8256C137S1E00FH Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, EPDM, 24/50Hz, IP67,
Art:
8256C137S1E00FQ Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, EPDM, 110V/50Hz, IP67,
Art:
8256C137S1E01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-4 bar, 0.14, EPDM, 24VDC, IP67,
Art:
8256C137S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-4 bar
0.14
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-4 bar, 0.14, EPDM, 12VDC, IP67,
Art:
8256C137S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-4 bar
0.14
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, EPDM, 230V/50Hz, IP67,
Art:
8256C137S1E01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, EPDM, 24/50Hz, IP67,
Art:
8256C137S1E01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, FPM, 110V/50Hz, IP67,
Art:
8256C137S1V00F0 Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-4 bar, 0.14, FPM, 24VDC, IP67,
Art:
8256C137S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-4 bar
0.14
24 VDC
EPDM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-4 bar, 0.14, FPM, 12VDC, IP67,
Art:
8256C137S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-4 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, FPM, 230V/50Hz, IP67,
Art:
8256C137S1V00FH Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-13 bar, 0.14, FPM, 24/50Hz, IP67,
Art:
8256C137S1V00FQ Copied
2/2, Normally Closed
1/8 NPT
0-13 bar
0.14
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, FPM, 110V/50Hz, IP67,
Art:
8256C137S1V01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
110V / 50 Hz
FPM
Brass
-10 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-4 bar, 0.14, FPM, 24VDC, IP67,
Art:
8256C137S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-4 bar
0.14
24 VDC
EPDM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-4 bar, 0.14, FPM, 12VDC, IP67,
Art:
8256C137S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-4 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, FPM, 230V/50Hz, IP67,
Art:
8256C137S1V01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-13 bar, 0.14, FPM, 24/50Hz, IP67,
Art:
8256C137S1V01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-13 bar
0.14
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
8256C138S1E00F0 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-2 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C138S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-2 bar
0.18
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-2 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C138S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-2 bar
0.18
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
8256C138S1E00FH Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
8256C138S1E00FQ Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
8256C138S1E01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-2 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C138S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-2 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-2 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C138S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-2 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
8256C138S1E01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
8256C138S1E01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
8256C138S1V00F0 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-2 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C138S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-2 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-2 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C138S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-2 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, FPM, 230V/50Hz, IP67,
Art:
8256C138S1V00FH Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
8256C138S1V00FQ Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
8256C138S1V01F0 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-2 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C138S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-2 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-2 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C138S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-2 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, FPM, 230V/50Hz, IP67,
Art:
8256C138S1V01FH Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
230V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
8256C138S1V01FQ Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-26 bar, 0.051, EPDM, 24VDC, IP67,
Art:
8256C149S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-26 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-26 bar, 0.051, EPDM, 12VDC, IP67,
Art:
8256C149S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-26 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-26 bar, 0.051, EPDM, 24VDC, IP67,
Art:
8256C149S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-26 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-26 bar, 0.051, EPDM, 12VDC, IP67,
Art:
8256C149S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-26 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-26 bar, 0.051, FPM, 24VDC, IP67,
Art:
8256C149S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-26 bar
0.051
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-26 bar, 0.051, FPM, 12VDC, IP67,
Art:
8256C149S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-26 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-26 bar, 0.051, FPM, 24VDC, IP67,
Art:
8256C149S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-26 bar
0.051
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-26 bar, 0.051, FPM, 12VDC, IP67,
Art:
8256C149S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-26 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-16 bar, 0.08, EPDM, 24VDC, IP67,
Art:
8256C150S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-16 bar
0.08
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-16 bar, 0.08, EPDM, 12VDC, IP67,
Art:
8256C150S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-16 bar
0.08
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-16 bar, 0.08, EPDM, 24VDC, IP67,
Art:
8256C150S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-16 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-16 bar, 0.08, EPDM, 12VDC, IP67,
Art:
8256C150S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-16 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-16 bar, 0.08, FPM, 24VDC, IP67,
Art:
8256C150S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-16 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-16 bar, 0.08, FPM, 12VDC, IP67,
Art:
8256C150S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-16 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-16 bar, 0.08, FPM, 24VDC, IP67,
Art:
8256C150S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-16 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-16 bar, 0.08, FPM, 12VDC, IP67,
Art:
8256C150S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-16 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.11, EPDM, 24VDC, IP67,
Art:
8256C151S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.11
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.11, EPDM, 12VDC, IP67,
Art:
8256C151S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.11
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.11, EPDM, 24VDC, IP67,
Art:
8256C151S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.11
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.11, EPDM, 12VDC, IP67,
Art:
8256C151S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.11
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.11, FPM, 24VDC, IP67,
Art:
8256C151S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.11
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-7 bar, 0.11, FPM, 12VDC, IP67,
Art:
8256C151S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-7 bar
0.11
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.11, FPM, 24VDC, IP67,
Art:
8256C151S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.11
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-7 bar, 0.11, FPM, 12VDC, IP67,
Art:
8256C151S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-7 bar
0.11
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.14, EPDM, 24VDC, IP67,
Art:
8256C152S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.14
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.14, EPDM, 12VDC, IP67,
Art:
8256C152S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.14
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.14, EPDM, 24VDC, IP67,
Art:
8256C152S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.14
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.14, EPDM, 12VDC, IP67,
Art:
8256C152S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.14
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.14, FPM, 24VDC, IP67,
Art:
8256C152S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-6 bar, 0.14, FPM, 12VDC, IP67,
Art:
8256C152S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-6 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.14, FPM, 24VDC, IP67,
Art:
8256C152S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.14
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-6 bar, 0.14, FPM, 12VDC, IP67,
Art:
8256C152S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-6 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-3 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C153S1E00F1 Copied
2/2, Normally Closed
1/8 NPT
0-3 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-3 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C153S1E00F3 Copied
2/2, Normally Closed
1/8 NPT
0-3 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-3 bar, 0.18, EPDM, 24VDC, IP67,
Art:
8256C153S1E01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-3 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-3 bar, 0.18, EPDM, 12VDC, IP67,
Art:
8256C153S1E01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-3 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-3 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C153S1V00F1 Copied
2/2, Normally Closed
1/8 NPT
0-3 bar
0.18
24 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., 1/8" NPT, 0-3 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C153S1V00F3 Copied
2/2, Normally Closed
1/8 NPT
0-3 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-3 bar, 0.18, FPM, 24VDC, IP67,
Art:
8256C153S1V01F1 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-3 bar
0.18
24 VDC
EPDM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, 1/8" NPT, 0-3 bar, 0.18, FPM, 12VDC, IP67,
Art:
8256C153S1V01F3 Copied
2/2, Normally Closed, Manual Override
1/8 NPT
0-3 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 110V/50Hz, IP67, Food Grade
Art:
8256C216S19DHF0 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
110V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24VDC, IP67, Food Grade
Art:
8256C216S19DHF1 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24 VDC
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 12VDC, IP67, Food Grade
Art:
8256C216S19DHF3 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
12 VDC
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 230V/50Hz, IP67, Food Grade
Art:
8256C216S19DHFH Copied
2/2, Normally open
G1/4
0-4 bar
0.3
230V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24/50Hz, IP67, Food Grade
Art:
8256C216S19DHFQ Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 110V/50Hz, IP67,
Art:
8256C216S19DQF0 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
110V / 50 Hz
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24VDC, IP67,
Art:
8256C216S19DQF1 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24 VDC
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 12VDC, IP67,
Art:
8256C216S19DQF3 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
12 VDC
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 230V/50Hz, IP67,
Art:
8256C216S19DQFH Copied
2/2, Normally open
G1/4
0-4 bar
0.3
230V / 50 Hz
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24/50Hz, IP67,
Art:
8256C216S19DQFQ Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24V / 50 Hz
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, EPDM, 110V/50Hz, IP67,
Art:
8256C230S1E00F0 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, EPDM, 230V/50Hz, IP67,
Art:
8256C230S1E00FH Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, EPDM, 24/50Hz, IP67,
Art:
8256C230S1E00FQ Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, FPM, 110V/50Hz, IP67,
Art:
8256C230S1V00F0 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
110V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, FPM, 230V/50Hz, IP67,
Art:
8256C230S1V00FH Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
230V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, FPM, 24/50Hz, IP67,
Art:
8256C230S1V00FQ Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
24V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
8256C231S1E00F0 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
8256C231S1E00FH Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
8256C231S1E00FQ Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
8256C231S1V00F0 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
110V / 50 Hz
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, FPM, 230V/50Hz, IP67,
Art:
8256C231S1V00FH Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
230V / 50 Hz
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
8256C231S1V00FQ Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, EPDM, 24VDC, IP67,
Art:
8256C246S1E00F1 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
24 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, EPDM, 12VDC, IP67,
Art:
8256C246S1E00F3 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
12 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, FPM, 24VDC, IP67,
Art:
8256C246S1V00F1 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
24 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-17 bar, 0.05, FPM, 12VDC, IP67,
Art:
8256C246S1V00F3 Copied
2/2, Normally open
1/8 NPT
0-17 bar
0.05
12 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-10 bar, 0.08, EPDM, 24VDC, IP67,
Art:
8256C247S1E00F1 Copied
2/2, Normally open
1/8 NPT
0-10 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-10 bar, 0.08, EPDM, 12VDC, IP67,
Art:
8256C247S1E00F3 Copied
2/2, Normally open
1/8 NPT
0-10 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-10 bar, 0.08, FPM, 24VDC, IP67,
Art:
8256C247S1V00F1 Copied
2/2, Normally open
1/8 NPT
0-10 bar
0.08
24 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., 1/8" NPT, 0-10 bar, 0.08, FPM, 12VDC, IP67,
Art:
8256C247S1V00F3 Copied
2/2, Normally open
1/8 NPT
0-10 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 110V/50Hz, IP67,
Art:
G256C102S1E00F0 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 24VDC, IP67,
Art:
G256C102S1E00F1 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 12VDC, IP67,
Art:
G256C102S1E00F3 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 230V/50Hz, IP67,
Art:
G256C102S1E00FH Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 24/50Hz, IP67,
Art:
G256C102S1E00FQ Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 110V/50Hz, IP67,
Art:
G256C102S1V00F0 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
110V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 12VDC, IP67,
Art:
G256C102S1V00F3 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 24/50Hz, IP67,
Art:
G256C102S1V00FQ Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24V / 50 Hz
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-18 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C104S1E00F1 Copied
2/2, Normally Closed
G1/4
0-18 bar
0.18
24 VDC
EPDM
Brass
-10 °C
130 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-18 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C104S1E00F3 Copied
2/2, Normally Closed
G1/4
0-18 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-18 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C104S1V00F3 Copied
2/2, Normally Closed
G1/4
0-18 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.3, EPDM, 24VDC, IP67,
Art:
G256C106S1E00F1 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.3
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.3, EPDM, 12VDC, IP67,
Art:
G256C106S1E00F3 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.3
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.3, FPM, 12VDC, IP67,
Art:
G256C106S1V00F3 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.3
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-3 bar, 0.4, EPDM, 24VDC, IP67,
Art:
G256C107S1E00F1 Copied
2/2, Normally Closed
G1/4
0-3 bar
0.4
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-3 bar, 0.4, EPDM, 12VDC, IP67,
Art:
G256C107S1E00F3 Copied
2/2, Normally Closed
G1/4
0-3 bar
0.4
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-3 bar, 0.4, FPM, 12VDC, IP67,
Art:
G256C107S1V00F3 Copied
2/2, Normally Closed
G1/4
0-3 bar
0.4
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-2 bar, 0.48, EPDM, 24VDC, IP67,
Art:
G256C108S1E00F1 Copied
2/2, Normally Closed
G1/4
0-2 bar
0.48
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-2 bar, 0.48, EPDM, 12VDC, IP67,
Art:
G256C108S1E00F3 Copied
2/2, Normally Closed
G1/4
0-2 bar
0.48
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-2 bar, 0.48, FPM, 12VDC, IP67,
Art:
G256C108S1V00F3 Copied
2/2, Normally Closed
G1/4
0-2 bar
0.48
12 VDC
FPM
Brass
0 °C
130 °C
5 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 24VDC, IP67,
Art:
G256C119S1E00F1 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, EPDM, 12VDC, IP67,
Art:
G256C119S1E00F3 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-30 bar, 0.1, FPM, 12VDC, IP67,
Art:
G256C119S1V00F3 Copied
2/2, Normally Closed
G1/4
0-30 bar
0.1
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
1.6 mm
1.59 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
G256C121S1E00F0 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C121S1E00F1 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C121S1E00F3 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
G256C121S1E00FH Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
G256C121S1E00FQ Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
G256C121S1V00F0 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C121S1V00F3 Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
12 VDC
EPDM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-20 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
G256C121S1V00FQ Copied
2/2, Normally Closed
G1/4
0-20 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
2.4 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, EPDM, 110V/50Hz, IP67,
Art:
G256C123S1E00F0 Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-12 bar, 0.3, EPDM, 24VDC, IP67,
Art:
G256C123S1E00F1 Copied
2/2, Normally Closed
G1/4
0-12 bar
0.3
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-12 bar, 0.3, EPDM, 12VDC, IP67,
Art:
G256C123S1E00F3 Copied
2/2, Normally Closed
G1/4
0-12 bar
0.3
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, EPDM, 230V/50Hz, IP67,
Art:
G256C123S1E00FH Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, EPDM, 24/50Hz, IP67,
Art:
G256C123S1E00FQ Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, FPM, 110V/50Hz, IP67,
Art:
G256C123S1V00F0 Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-12 bar, 0.3, FPM, 24VDC, IP67,
Art:
G256C123S1V00F1 Copied
2/2, Normally Closed
G1/4
0-12 bar
0.3
24 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-12 bar, 0.3, FPM, 12VDC, IP67,
Art:
G256C123S1V00F3 Copied
2/2, Normally Closed
G1/4
0-12 bar
0.3
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, FPM, 230V/50Hz, IP67,
Art:
G256C123S1V00FH Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
230V / 50 Hz
EPDM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-15 bar, 0.3, FPM, 24/50Hz, IP67,
Art:
G256C123S1V00FQ Copied
2/2, Normally Closed
G1/4
0-15 bar
0.3
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
3.2 mm
5.03 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, EPDM, 110V/50Hz, IP67,
Art:
G256C124S1E00F0 Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.4, EPDM, 12VDC, IP67,
Art:
G256C124S1E00F3 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.4
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, EPDM, 230V/50Hz, IP67,
Art:
G256C124S1E00FH Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
5 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, EPDM, 24/50Hz, IP67,
Art:
G256C124S1E00FQ Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, FPM, 110V/50Hz, IP67,
Art:
G256C124S1V00F0 Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-6 bar, 0.4, FPM, 12VDC, IP67,
Art:
G256C124S1V00F3 Copied
2/2, Normally Closed
G1/4
0-6 bar
0.4
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-8 bar, 0.4, FPM, 24/50Hz, IP67,
Art:
G256C124S1V00FQ Copied
2/2, Normally Closed
G1/4
0-8 bar
0.4
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
4.5 mm
6.64 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, EPDM, 110V/50Hz, IP67,
Art:
G256C125S1E00F0 Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-4 bar, 0.48, EPDM, 24VDC, IP67,
Art:
G256C125S1E00F1 Copied
2/2, Normally Closed
G1/4
0-4 bar
0.48
24 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-4 bar, 0.48, EPDM, 12VDC, IP67,
Art:
G256C125S1E00F3 Copied
2/2, Normally Closed
G1/4
0-4 bar
0.48
12 VDC
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, EPDM, 230V/50Hz, IP67,
Art:
G256C125S1E00FH Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, EPDM, 24/50Hz, IP67,
Art:
G256C125S1E00FQ Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, FPM, 110V/50Hz, IP67,
Art:
G256C125S1V00F0 Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
110V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-4 bar, 0.48, FPM, 12VDC, IP67,
Art:
G256C125S1V00F3 Copied
2/2, Normally Closed
G1/4
0-4 bar
0.48
12 VDC
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/4", 0-5 bar, 0.48, FPM, 24/50Hz, IP67,
Art:
G256C125S1V00FQ Copied
2/2, Normally Closed
G1/4
0-5 bar
0.48
24V / 50 Hz
FPM
Brass
0 °C
130 °C
9 W
70 ms
0.3 kg
5 mm
7.92 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, EPDM, 110V/50Hz, IP67,
Art:
G256C134S1E00F0 Copied
2/2, Normally Closed
G1/8
0-30 bar
0.051
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-20 bar, 0.051, EPDM, 24VDC, IP67,
Art:
G256C134S1E00F1 Copied
2/2, Normally Closed
G1/8
0-20 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-20 bar, 0.051, EPDM, 12VDC, IP67,
Art:
G256C134S1E00F3 Copied
2/2, Normally Closed
G1/8
0-20 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, EPDM, 230V/50Hz, IP67,
Art:
G256C134S1E00FH Copied
2/2, Normally Closed
G1/8
0-30 bar
0.051
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, EPDM, 24/50Hz, IP67,
Art:
G256C134S1E00FQ Copied
2/2, Normally Closed
G1/8
0-30 bar
0.051
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, EPDM, 110V/50Hz, IP67,
Art:
G256C134S1E01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.051
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-20 bar, 0.051, EPDM, 24VDC, IP67,
Art:
G256C134S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-20 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-20 bar, 0.051, EPDM, 12VDC, IP67,
Art:
G256C134S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-20 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, EPDM, 230V/50Hz, IP67,
Art:
G256C134S1E01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.051
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, EPDM, 24/50Hz, IP67,
Art:
G256C134S1E01FQ Copied
2/2, Manual Override, Normally Closed
G1/8
0-30 bar
0.051
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, FPM, 110V/50Hz, IP67,
Art:
G256C134S1V00F0 Copied
2/2, Normally Closed
G1/8
0-30 bar
0.051
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-20 bar, 0.051, FPM, 12VDC, IP67,
Art:
G256C134S1V00F3 Copied
2/2, Normally Closed
G1/8
0-20 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.051, FPM, 24/50Hz, IP67,
Art:
G256C134S1V00FQ Copied
2/2, Normally Closed
G1/8
0-30 bar
0.051
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, FPM, 110V/50Hz, IP67,
Art:
G256C134S1V01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.051
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-20 bar, 0.051, FPM, 12VDC, IP67,
Art:
G256C134S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-20 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.051, FPM, 24/50Hz, IP67,
Art:
G256C134S1V01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.051
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
G256C135S1E00F0 Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-12 bar, 0.08, EPDM, 24VDC, IP67,
Art:
G256C135S1E00F1 Copied
2/2, Normally Closed
G1/8
0-12 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-12 bar, 0.08, EPDM, 12VDC, IP67,
Art:
G256C135S1E00F3 Copied
2/2, Normally Closed
G1/8
0-12 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
G256C135S1E00FH Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
G256C135S1E00FQ Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
G256C135S1E01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-12 bar, 0.08, EPDM, 24VDC, IP67,
Art:
G256C135S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-12 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-12 bar, 0.08, EPDM, 12VDC, IP67,
Art:
G256C135S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-12 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
G256C135S1E01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
G256C135S1E01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
G256C135S1V00F0 Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-12 bar, 0.08, FPM, 12VDC, IP67,
Art:
G256C135S1V00F3 Copied
2/2, Normally Closed
G1/8
0-12 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-30 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
G256C135S1V00FQ Copied
2/2, Normally Closed
G1/8
0-30 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
G256C135S1V01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-12 bar, 0.08, FPM, 12VDC, IP67,
Art:
G256C135S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-12 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-30 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
G256C135S1V01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-30 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, EPDM, 110V/50Hz, IP67,
Art:
G256C136S1E00F0 Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.12, EPDM, 24VDC, IP67,
Art:
G256C136S1E00F1 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.12
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.12, EPDM, 12VDC, IP67,
Art:
G256C136S1E00F3 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.12
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, EPDM, 230V/50Hz, IP67,
Art:
G256C136S1E00FH Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, EPDM, 24/50Hz, IP67,
Art:
G256C136S1E00FQ Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, EPDM, 110V/50Hz, IP67,
Art:
G256C136S1E01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.12, EPDM, 24VDC, IP67,
Art:
G256C136S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.12
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.12, EPDM, 12VDC, IP67,
Art:
G256C136S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.12
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, EPDM, 230V/50Hz, IP67,
Art:
G256C136S1E01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, EPDM, 24/50Hz, IP67,
Art:
G256C136S1E01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, FPM, 110V/50Hz, IP67,
Art:
G256C136S1V00F0 Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.12, FPM, 12VDC, IP67,
Art:
G256C136S1V00F3 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.12
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-15 bar, 0.12, FPM, 24/50Hz, IP67,
Art:
G256C136S1V00FQ Copied
2/2, Normally Closed
G1/8
0-15 bar
0.12
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, FPM, 110V/50Hz, IP67,
Art:
G256C136S1V01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.12, FPM, 12VDC, IP67,
Art:
G256C136S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.12
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-15 bar, 0.12, FPM, 24/50Hz, IP67,
Art:
G256C136S1V01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-15 bar
0.12
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2 mm
1.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, EPDM, 110V/50Hz, IP67,
Art:
G256C137S1E00F0 Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
110V/50 Hz
EPDM
Brass
-10 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-4 bar, 0.14, EPDM, 24VDC, IP67,
Art:
G256C137S1E00F1 Copied
2/2, Normally Closed
G1/8
0-4 bar
0.14
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-4 bar, 0.14, EPDM, 12VDC, IP67,
Art:
G256C137S1E00F3 Copied
2/2, Normally Closed
G1/8
0-4 bar
0.14
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, EPDM, 230V/50Hz, IP67,
Art:
G256C137S1E00FH Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, EPDM, 24/50Hz, IP67,
Art:
G256C137S1E00FQ Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, EPDM, 110V/50Hz, IP67,
Art:
G256C137S1E01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-13 bar
0.14
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-4 bar, 0.14, EPDM, 24VDC, IP67,
Art:
G256C137S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-4 bar
0.14
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-4 bar, 0.14, EPDM, 12VDC, IP67,
Art:
G256C137S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-4 bar
0.14
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, EPDM, 230V/50Hz, IP67,
Art:
G256C137S1E01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-13 bar
0.14
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, EPDM, 24/50Hz, IP67,
Art:
G256C137S1E01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-13 bar
0.14
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, FPM, 110V/50Hz, IP67,
Art:
G256C137S1V00F0 Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-4 bar, 0.14, FPM, 12VDC, IP67,
Art:
G256C137S1V00F3 Copied
2/2, Normally Closed
G1/8
0-4 bar
0.14
12 VDC
FPM
Brass
0 °C
140 °C
3.5W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-13 bar, 0.14, FPM, 24/50Hz, IP67,
Art:
G256C137S1V00FQ Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, FPM, 110V/50Hz, IP67,
Art:
G256C137S1V01F0 Copied
2/2, Normally Closed
G1/8
0-13 bar
0.14
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-4 bar, 0.14, FPM, 12VDC, IP67,
Art:
G256C137S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-4 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-13 bar, 0.14, FPM, 24/50Hz, IP67,
Art:
G256C137S1V01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-13 bar
0.14
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
G256C138S1E00F0 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
110V/50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-2 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C138S1E00F1 Copied
2/2, Normally Closed
G1/8
0-2 bar
0.18
24VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-2 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C138S1E00F3 Copied
2/2, Normally Closed
G1/8
0-2 bar
0.18
12VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
G256C138S1E00FH Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
230V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
G256C138S1E00FQ Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
24V/50Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, EPDM, 110V/50Hz, IP67,
Art:
G256C138S1E01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-2 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C138S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-2 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-2 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C138S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-2 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, EPDM, 230V/50Hz, IP67,
Art:
G256C138S1E01FH Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.18
230 / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, EPDM, 24/50Hz, IP67,
Art:
G256C138S1E01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.18
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
G256C138S1V00F0 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-2 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C138S1V00F3 Copied
2/2, Normally Closed
G1/8
0-2 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
G256C138S1V00FQ Copied
2/2, Normally Closed
G1/8
0-7 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, FPM, 110V/50Hz, IP67,
Art:
G256C138S1V01F0 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.18
110V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-2 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C138S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-2 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.18, FPM, 24/50Hz, IP67,
Art:
G256C138S1V01FQ Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.18
24V / 50 Hz
FPM
Brass
0 °C
130 °C
3.5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-26 bar, 0.051, EPDM, 24VDC, IP67,
Art:
G256C149S1E00F1 Copied
2/2, Normally Closed
G1/8
0-26 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-26 bar, 0.051, EPDM, 12VDC, IP67,
Art:
G256C149S1E00F3 Copied
2/2, Normally Closed
G1/8
0-26 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-26 bar, 0.051, EPDM, 24VDC, IP67,
Art:
G256C149S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-26 bar
0.051
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-26 bar, 0.051, EPDM, 12VDC, IP67,
Art:
G256C149S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-26 bar
0.051
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-26 bar, 0.051, FPM, 12VDC, IP67,
Art:
G256C149S1V00F3 Copied
2/2, Normally Closed
G1/8
0-26 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-26 bar, 0.051, FPM, 12VDC, IP67,
Art:
G256C149S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-26 bar
0.051
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-16 bar, 0.08, EPDM, 24VDC, IP67,
Art:
G256C150S1E00F1 Copied
2/2, Normally Closed
G1/8
0-16 bar
0.08
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-16 bar, 0.08, EPDM, 12VDC, IP67,
Art:
G256C150S1E00F3 Copied
2/2, Normally Closed
G1/8
0-16 bar
0.08
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-16 bar, 0.08, EPDM, 24VDC, IP67,
Art:
G256C150S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-16 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-16 bar, 0.08, EPDM, 12VDC, IP67,
Art:
G256C150S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-16 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-16 bar, 0.08, FPM, 12VDC, IP67,
Art:
G256C150S1V00F3 Copied
2/2, Normally Closed
G1/8
0-16 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-16 bar, 0.08, FPM, 12VDC, IP67,
Art:
G256C150S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-16 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.11, EPDM, 24VDC, IP67,
Art:
G256C151S1E00F1 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.11
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.11, EPDM, 12VDC, IP67,
Art:
G256C151S1E00F3 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.11
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.11, EPDM, 24VDC, IP67,
Art:
G256C151S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.11
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.11, EPDM, 12VDC, IP67,
Art:
G256C151S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.11
12 VDC
FPM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-7 bar, 0.11, FPM, 12VDC, IP67,
Art:
G256C151S1V00F3 Copied
2/2, Normally Closed
G1/8
0-7 bar
0.11
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-7 bar, 0.11, FPM, 12VDC, IP67,
Art:
G256C151S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-7 bar
0.11
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2 mm
1.83 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.14, EPDM, 24VDC, IP67,
Art:
G256C152S1E00F1 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.14
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.14, EPDM, 12VDC, IP67,
Art:
G256C152S1E00F3 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.14
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.14, EPDM, 24VDC, IP67,
Art:
G256C152S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.14
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.14, EPDM, 12VDC, IP67,
Art:
G256C152S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.14
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-6 bar, 0.14, FPM, 12VDC, IP67,
Art:
G256C152S1V00F3 Copied
2/2, Normally Closed
G1/8
0-6 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-6 bar, 0.14, FPM, 12VDC, IP67,
Art:
G256C152S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-6 bar
0.14
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
2.4 mm
2.32 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-3 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C153S1E00F1 Copied
2/2, Normally Closed
G1/8
0-3 bar
0.18
24VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-3 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C153S1E00F3 Copied
2/2, Normally Closed
G1/8
0-3 bar
0.18
12VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-3 bar, 0.18, EPDM, 24VDC, IP67,
Art:
G256C153S1E01F1 Copied
2/2, Normally Closed, Manual Override
G1/8
0-3 bar
0.18
24 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-3 bar, 0.18, EPDM, 12VDC, IP67,
Art:
G256C153S1E01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-3 bar
0.18
12 VDC
EPDM
Brass
-10 °C
140 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C., G1/8", 0-3 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C153S1V00F3 Copied
2/2, Normally Closed
G1/8
0-3 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.C. Manual Override, G1/8", 0-3 bar, 0.18, FPM, 12VDC, IP67,
Art:
G256C153S1V01F3 Copied
2/2, Normally Closed, Manual Override
G1/8
0-3 bar
0.18
12 VDC
FPM
Brass
0 °C
130 °C
5 W
20 ms
0.116 kg
3.2 mm
2.99 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 110V/50Hz, IP67, Food Grade
Art:
G256C216S19DHF0 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
110V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24VDC, IP67, Food Grade
Art:
G256C216S19DHF1 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24 VDC
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 12VDC, IP67, Food Grade
Art:
G256C216S19DHF3 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
12 VDC
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 230V/50Hz, IP67, Food Grade
Art:
G256C216S19DHFH Copied
2/2, Normally open
G1/4
0-4 bar
0.3
230V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24/50Hz, IP67, Food Grade
Art:
G256C216S19DHFQ Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24V / 50 Hz
FPM Food approved
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 110V/50Hz, IP67,
Art:
G256C216S19DQF0 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
110V / 50 Hz
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 12VDC, IP67,
Art:
G256C216S19DQF3 Copied
2/2, Normally open
G1/4
0-4 bar
0.3
12 VDC
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/4", 0-4 bar, 0.3, FPM, 24/50Hz, IP67,
Art:
G256C216S19DQFQ Copied
2/2, Normally open
G1/4
0-4 bar
0.3
24V / 50 Hz
FPM
Stainless steel
0 °C
130 °C
9 W
70 ms
0.34 kg
3.2 mm
5 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, EPDM, 110V/50Hz, IP67,
Art:
G256C230S1E00F0 Copied
2/2, Normally open
G1/8
0-17 bar
0.05
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, EPDM, 230V/50Hz, IP67,
Art:
G256C230S1E00FH Copied
2/2, Normally open
G1/8
0-17 bar
0.05
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, EPDM, 24/50Hz, IP67,
Art:
G256C230S1E00FQ Copied
2/2, Normally open
G1/8
0-17 bar
0.05
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, FPM, 110V/50Hz, IP67,
Art:
G256C230S1V00F0 Copied
2/2, Normally open
G1/8
0-17 bar
0.05
110V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, FPM, 24/50Hz, IP67,
Art:
G256C230S1V00FQ Copied
2/2, Normally open
G1/8
0-17 bar
0.05
24V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.2 mm
0.85 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, EPDM, 110V/50Hz, IP67,
Art:
G256C231S1E00F0 Copied
2/2, Normally open
G1/8
0-17 bar
0.08
110V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, EPDM, 230V/50Hz, IP67,
Art:
G256C231S1E00FH Copied
2/2, Normally open
G1/8
0-17 bar
0.08
230V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, EPDM, 24/50Hz, IP67,
Art:
G256C231S1E00FQ Copied
2/2, Normally open
G1/8
0-17 bar
0.08
24V / 50 Hz
EPDM
Brass
-10 °C
140 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, FPM, 110V/50Hz, IP67,
Art:
G256C231S1V00F0 Copied
2/2, Normally open
G1/8
0-17 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.08, FPM, 24/50Hz, IP67,
Art:
G256C231S1V00FQ Copied
2/2, Normally open
G1/8
0-17 bar
0.08
24V / 50 Hz
FPM
Brass
0 °C
130 °C
6 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, EPDM, 24VDC, IP67,
Art:
G256C246S1E00F1 Copied
2/2, Normally open
G1/8
0-17 bar
0.05
24 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, EPDM, 12VDC, IP67,
Art:
G256C246S1E00F3 Copied
2/2, Normally open
G1/8
0-17 bar
0.05
12 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-17 bar, 0.05, FPM, 12VDC, IP67,
Art:
G256C246S1V00F3 Copied
2/2, Normally open
G1/8
0-17 bar
0.05
12 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.2 mm
0.83 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-10 bar, 0.08, EPDM, 24VDC, IP67,
Art:
G256C247S1E00F1 Copied
2/2, Normally open
G1/8
0-10 bar
0.08
24 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-10 bar, 0.08, EPDM, 12VDC, IP67,
Art:
G256C247S1E00F3 Copied
2/2, Normally open
G1/8
0-10 bar
0.08
12 VDC
EPDM
Brass
-10 °C
140 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min
256 Brass.jpg
2/2 N.O., G1/8", 0-10 bar, 0.08, FPM, 12VDC, IP67,
Art:
G256C247S1V00F3 Copied
2/2, Normally open
G1/8
0-10 bar
0.08
12 VDC
FPM
Brass
0 °C
130 °C
5.5 W
20 ms
0.116 kg
1.6 mm
1.33 l/min

Selected variant

Select a variant in the list

Contact us
If you need any help, you can contact us in one of the following ways:
0116 284 9900
Send e-mail
Use live chat
Do you need help?
Logo

Cookie settings for OEM.CO.UK

Cookies help us improve your experience with us, so in order to be able to handle login information, offer you personalised content and for basic functionality of this website, we use some cookies.

We will never sell on any information about you.

You can accept all cookies or personalise your cookies preferences, you can also change your cookie preferences at any time by visiting our contact page.

Necessary Cookies

These cookies are necessary for the website to work and can not be turned off in our systems. They are usually used only in response to actions you have taken in connection with a service request, for example when setting personal preferences, logging in or filling out a form.

Analysis and measurement cookies

These cookies allow us to count the number of visits and traffic sources so that we can measure and improve our website performance. They help us know which pages are more or less popular and how visitors navigate around the site. The information that these cookies collect is aggregated and therefore completely anonymous. If you do not allow these cookies, we do not know when you have visited our website.

Marketing cookies

These cookies can be added by our partners. They can use them to create a profile of you, based on your interests, to show you more relevant information. They do not store any personal information - only information about your browser and device. If you do not accept these cookies, you will have a more general and less customized user experience.
