General Data |
|
---|---|
Function | 3/2, Normally Closed |
Flow factor / flow coefficient | 0,08 |
IP class | IP65 |
Material Data |
|
Material body | Brass |
Material of seals | FPM |
Material seat | Brass |
Temperature Data |
|
Temperature of media from | -10 °C |
Temperature of media to | 100 °C |
Additional Data |
|
---|---|
Close delay | 5 ms |
Viscosity max | 40 cSt |
Approvals | CSA, UL |
Weight | 0.321 kg |
Power consumption | 4 W |
Throughput | 1.6 mm |
Response time off | 10 ms |
Voltage ac max | 230 V |
Temperature operational min | -10 °C |
Temperature operational max | 60 °C |
Connection port 1-2 | G1/8 |
Connection port 3 | M5 |
Differential air pressure max | 10 bar |
Differential pressure min | 0 bar |
Differential oil pressure max | 10 bar |
Differential water pressure max | 10 bar |
Flow max | 1.33 l/min |
Material plunger | Stainless steel |
Material short-circuit ring | Copper |
Material seat seal | FPM |
Material spring | Stainless steel |
Number of valves | 2 Â |
OEM Automatics water and wastewater application specialists have gathered all our solutions in one place. Our products are used in everything from small municipal water works to larger regional plants.
Whether you’re pumping water, chocolate, oil or peanut butter knowing the product’s viscosity is essential to selecting the right pump. Find out more about viscosity and which pump may be suitable for your application!
Whether you're looking to upgrade your current solution or secure a more robust float switch for your next project, Taurus delivers performance you can count on.
When choosing between a pressure switch and a pressure sensor, the key lies in understanding your application. Our Pressure Monitoring experts breaks down the two devices for you.
Pumps are now officially part of our product offering! As we build our pump portfolio, we’re proud to announce that we are an official distributor of SAMOA Industrial, a well-established name in the fluid handling industry.
OEM Automatic's barcode scanner experts have broken down barcode technology to help you choose the right scanner for your application!
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Flow factor / flow coefficient | Weight | Throughput | Differential air pressure max | Differential pressure min | Differential oil pressure max | Differential water pressure max | Flow max | Number of valves | Price | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|
![]()
2 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A819V
Copied
|
0,08
|
0.321 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
2
|
| ||
![]()
3 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A820V
Copied
|
0,08
|
0.426 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
3
|
| ||
![]()
4 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A821V
Copied
|
0,08
|
0.531 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
4
|
| ||
![]()
5 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A822V
Copied
|
0,08
|
0.636 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
5
|
| ||
![]()
6 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A823V
Copied
|
0,08
|
0.741 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
6
|
| ||
![]()
7 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A824V
Copied
|
0,08
|
0.846 kg
|
1.6 mm
|
10 bar
|
0 bar
|
10 bar
|
10 bar
|
1.33 l/min
|
7
|
| ||
![]()
8 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A825V
Copied
|
0,08
|
0.951 kg
|
1.6 mm
|
10 bar
|
|
10 bar
|
10 bar
|
1.33 l/min
|
8
|
| ||
![]()
9 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A826V
Copied
|
0,08
|
1.056 kg
|
1.6 mm
|
10 bar
|
|
10 bar
|
10 bar
|
1.33 l/min
|
9
|
| ||
![]()
10 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A827V
Copied
|
0,08
|
1.161 kg
|
1.6 mm
|
10 bar
|
|
10 bar
|
10 bar
|
1.33 l/min
|
10
|
| ||
![]()
2 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A855V
Copied
|
0,13
|
0.321 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
2
|
| ||
![]()
3 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A856V
Copied
|
0,13
|
0.426 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
3
|
| ||
![]()
4 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A857V
Copied
|
0,13
|
0.531 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
4
|
| ||
![]()
5 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A858V
Copied
|
0,13
|
0.636 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
5
|
| ||
![]()
6 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A859V
Copied
|
0,13
|
0.741 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
6
|
| ||
![]()
7 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A860V
Copied
|
0,13
|
0.846 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
7
|
| ||
![]()
8 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A861V
Copied
|
0,13
|
0.951 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
8
|
| ||
![]()
9 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A862V
Copied
|
0,13
|
1.056 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
9
|
| ||
![]()
10 valve manifold, N/C, 3/2, 1/8", 230VAC
Art:
SCG356A863V
Copied
|
0,13
|
1.161 kg
|
2.4 mm
|
4 bar
|
0 bar
|
4 bar
|
4 bar
|
2.16 l/min
|
10
|
|
