ASCO
ASCO - 215 Series Direct Operated
2/2
- Normally closed
- Housing in aluminium
- Working pressure 0 bar to 3.5 bar
Selected variant
Technical data
General Data |
|
|---|---|
| Connection | 3/8 BSP |
| Flow factor / flow coefficient | 2,9 |
| IP class | IP65 |
Material Data |
|
| Material body | Aluminium |
| Material of seals | NBR |
| Material seat | Aluminium |
Temperature Data |
|
| Temperature of media from | -20 °C |
| Temperature of media to | 85 °C |
Additional Data |
|
|---|---|
| Weight | 0.6 kg |
| Power consumption | 10.5 W |
| Throughput | 19 mm |
| Type of valve | Solenoid valve |
| Voltage AC | 230 V |
| Temperature operational min | -20 °C |
| Temperature operational max | 75 °C |
| Material coil | Epoxy |
| Differential air pressure max | 3.5 bar |
| Differential pressure max | 3.5 bar |
| Differential pressure min | 0 bar |
| Flow max | 48.3 l/min |
| Function 1 | 2/2 |
| Function 2 | Normally Closed |
| Material plunger | Stainless steel |
| Material short-circuit ring | Copper |
| Material glide ring | PTFE |
| Material spring | Stainless steel |
