SENSECA
The CV series flow indicator from Val.Co allows a visual inspection of the passage of liquids in hydraulic and water systems. The propeller is coloured for better visualization with opaque liquids and there is also an option for a blue propeller and an output.
Colour of rotor | Red |
---|---|
Flow range max | 10 l/min |
Manufacturer part no. | CV.008G.PSO.R |
Material of body | Latene |
Material of connection | Brass |
Material of glass tube | Pyrex glass |
Material of rotor | Polypropylene |
Material of seals | NBR |
Min flow rate for rotor (oil 40 Cst) l/min | 2.5 |
---|---|
Min flow rate for rotor (oil 41-150 Cst) l/min | 3.5 |
Min flow rate for rotor (water) l/min | 0.6 |
Pressure drop (bar) | 0.15 |
Pressure max | 25 bar |
Process connection | 1/4 BSP |
Temperature operational max | 100 °C |
The CV series flow indicator from Val.Co allows a visual inspection of the passage of liquids in hydraulic and water systems. The propeller is coloured for better visualization with opaque liquids and there is also an option for a blue propeller and an output.
Pumps are now officially part of our product offering! As we build our pump portfolio, we’re proud to announce that we are an official distributor of SAMOA Industrial, a well-established name in the fluid handling industry.
This blog post demonstrates 7 strong reasons production plants choose the HYGHSPIN twin screw pump by Jung Process Systems
When selecting a SUCO mechanical pressure switch, it's essential to consider several key factors...
When it comes to solenoid valves, reliability and ease of maintenance are essential. That’s why our new Emerson, high flow solenoid valve is designed with unique features that streamline testing, commissioning, and ongoing operation.Â
Did you get a chance to visit IATECH at The Leicester Marriott Hotel? We had over 33 exhibitors and 8 fantastic Tech Talks throughout the day, Read all about the day, here.
Did you know that OEM Automatic has been successfully providing valve actuation solutions?
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Flow range max | Manufacturer part no. | Min flow rate for rotor (oil 40 Cst) l/min | Min flow rate for rotor (oil 41-150 Cst) l/min | Min flow rate for rotor (water) l/min | Pressure drop (bar) | Pressure max | Process connection | Price | ||
---|---|---|---|---|---|---|---|---|---|---|---|
![]()
0,6..10 l/min H2O, G1/4F, Brass
Art:
00.0006.0057.1
Copied
|
10 l/min
|
CV.008G.PSO.R
|
2.5
|
3.5
|
0.6
|
0.15
|
25 bar
|
1/4 BSP
|
| ||
![]()
1,2..20 l/min H2O, G3/8F, Brass
Art:
00.0006.0058.1
Copied
|
20 l/min
|
CV.010G.PSO.R
|
3
|
4
|
1.2
|
0.25
|
15 bar
|
G3/8
|
| ||
![]()
1,2..40 l/min H2O, G1/2F, Brass
Art:
00.0006.0059.1
Copied
|
40 l/min
|
CV.015G.PSO.R
|
3
|
4
|
1.2
|
0.3
|
15 bar
|
G1/2
|
| ||
![]()
2,1..60 l/min H2O, G3/4F, Brass
Art:
00.0006.0060.1
Copied
|
60 l/min
|
CV.020G.PSO.R
|
3.7
|
5
|
2.1
|
0.17
|
12 bar
|
G3/4
|
| ||
![]()
2,1..80 l/min H2O, G1F, Brass
Art:
00.0006.0061.1
Copied
|
80 l/min
|
CV.025G.PSO.R
|
3.7
|
5
|
2.1
|
0.15
|
12 bar
|
G1
|
|
Select a variant in the list
