Selected variant
Technical data
Input Data |
|
|---|---|
| Control voltage dc max | 48 V |
| Control voltage dc min | 5 V |
| Input current at nominal voltage, typ | 10 mA |
| Response time | 10 ms |
Output Data |
|
| Number of contacts | 1 |
| Load voltage ac max | 250 V |
| Load voltage ac min | 24 V |
| Breaking capacity current | 3 A |
| Recommended min load | 35 mA |
| 2421_Peak current (A) | 150 A / 10ms |
*Invisible Heading* |
|
|---|---|
| Release time | 10 ms |
General Data |
|
| Width | 14 mm |
| Temperature operational min | -40 °C |
| Storage temperature min | -40 °C |
| Storage temperature max | 85 °C |
| Temperature operational max | 70 °C |
| Weight | 28 g |
| I2t value | 210 A²s |
