PKB 1110

The PKB 1110 series from Conta-Clip is a versatile range of screw-connection female socket terminal blocks designed for secure and reliable wire-to-board connections. With a 5.00 mm pitch, these terminal blocks are available in various pole configurations, such as 2, 3, 4, 5, 6, and 7 poles, accommodating conductor cross-sections from 0.2 mm² to 4 mm² for rigid wires and up to 2.5 mm² for stranded wires with ferrules. The terminals are rated for a maximum current of 10 A and a voltage of 250 V, with an impulse voltage resistance of 4 kV, making them suitable for applications requiring high electrical performance. They feature M3 screw connections with a 7 mm stripping length, ensuring secure and vibration-resistant terminations. Constructed from flame-retardant polyamide 6.6 (UL 94 V-0), these terminal blocks offer durability and compliance with international safety standards.

The PKB 1110 series is ideal for use in industrial control systems, automation equipment, and power distribution modules, where space-saving and reliable connections are essential. The angled design of the terminals, with a 270° wire connection angle, facilitates easy integration into compact PCBs and enclosures. The screw connection system ensures secure and maintenance-friendly wiring, while the robust construction withstands demanding environments. With certifications including UL, cUL, and VDE, the PKB 1110 series meets international safety standards, making it suitable for global applications. Whether for new designs or retrofitting existing systems, these terminal blocks provide engineers with a dependable solution for dense and durable PCB interconnections.
