Clamping Yoke Female Socket Plugs
PKB 1550, 1551, 1552
- Push In Connection
- Multiple Conductor Options
- 0.2 mm² to 2.5 mm² Wire Cross Sections
- Up to 500 V and 24 A
PKBZ 1551
- female socket terminals
- Screw Connection
- Conductors from 0.14 mm² to 1.5 mm²
PKBZ 1552
- Push In Connection
- Wire Cross Section up to 2.5 mm
- compatible with various mounting rails
PKB 950, 955
- Various Pole Configurations
- Conductor cross-sections from 0.2 mm² to 4 mm²
- Impulse voltage resistance of 4 kV
- Can be coded
PKB 1100
- Various Pole Configurations
- Conductor cross-sections from 0.2 mm² to 4 mm²
- Impulse voltage resistance of 4 kV
- Can be coded
PKB 1110
- Various Pole Configurations
- Conductor cross-sections from 0.2 mm² to 4 mm²
- Impulse voltage resistance of 4 kV
- can be coded
PKBZ 950/955
- 2 to 24 Poles
- Impulse Voltage Resistance
- Fast replacement or maintenance
- Screw-terminal
PKBZ 1100/1110
- conductor ranges between 0.14–2.5 mm²
- Supports 10 A at voltages between 250 V and 630 V
- Screw torque around 0.4 Nm to 0.6 Nm
PKBZ 965
- 6 kV impulse voltage
- Pluggable female socket blocks
- 2 to 16 poles
PKB 960
- 2 to 16 Poles
- Impulse voltage resistance of 6 kV
- Flame-retardant polyamide 6.6
- 7.62 mm Pitch
IPKBZ 950
