| Actuation force min | 15 N |
|---|---|
| Cable length | 2000 mm |
| Contact type | Changeover (SPDT) |
| Conventional thermal current | 12 A |
| Hysteresis max | 2 mm |
| IP class | IP66 |
| Operating power total min | 35 N |
|---|---|
| Rated current at 250 V ac | 5 A |
| Temperature operational max | 70 °C |
| Temperature operational min | -5 °C |
| Voltage max | 250 V |
We are pleased to announce that OEM Automatic Ltd has acquired Motion29 Ltd. Bringing together the expertise, products, and services of both organisations under both the OEM and Motion29 brands, strengthening our overall offering.
Discover how fault masking is compromising the safety of your workplace and find out how OEM Automatic can help you to prevent it completely. Creating a safe and secure work environment.
Learn more about Inxpect radar systems. The worlds first SIL 2/PL d certified, radar-based safety system for use around hazardous machinery.
Whether you're working with opaque materials or transparent items like glass or plastic, these sensors deliver reliable performance across a wide range of applications.
OEM Automatics Safety Experts guide you through the process of setting up your light curtains & barriers, to protect your people and equipment.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Actuation force min | Cable length | Contact type | Conventional thermal current | Hysteresis max | IP class | Operating power total min | Rated current at 250 V ac | Temperature operational max | Temperature operational min | Voltage max | Price | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
837313 C/O 2.00M
Art:
83731310
Copied
|
15 N
|
2000 mm
|
Changeover (SPDT)
|
12 A
|
2 mm
|
IP66
|
35 N
|
5 A
|
70 °C
|
-5 °C
|
250 V
|
|
||
|
Limit switch CO 5A 250VAC IP66
Art:
83732327
Copied
|
15 N
|
2000 mm
|
Changeover (SPDT)
|
12 A
|
2 mm
|
IP56
|
35 N
|
5 A
|
70 °C
|
-5 °C
|
250 V
|
|
||
|
837333 C/O 2.00M
Art:
83733310
Copied
|
6 N
|
2000 mm
|
Changeover (SPDT)
|
12 A
|
1.5 mm
|
IP56
|
25 N
|
5 A
|
70 °C
|
-5 °C
|
250 V
|
|
||
|
Limit switch, Specific, 8373 Series, 837
Art:
83733321
Copied
|
|
|
|
|
|
|
|
|
|
|
|
|
Select a variant in the list
