Inductive sensors are used for position indication, impulse or motion detector for metallic objects. The sensor has no moving parts and is therefore suitable for applications with high contact frequency. Due to the compact and easy-mounted design of the sensor as well as the contact-free function, the sensor is normally not subjected to mechanical wear.
Cable length | 2000 mm |
---|---|
Electrical connection | Embedded 2m cable |
IP class | IP67 |
LED indicator | Yes |
Material of body | Nickel-plated brass |
Mounting | Flush |
Output | PNP, NO, NC |
Output current max | 0.2 A |
Reaction time | 75 ms |
Sensing distance | 15 mm |
---|---|
Sensor Type | Inductive |
Size | M30 |
Supply voltage | 10-30 V DC |
Temperature operational max | 70 °C |
Temperature operational min | -25 °C |
Weight | 210 g |
Inductive sensors are used for position indication, impulse or motion detector for metallic objects. The sensor has no moving parts and is therefore suitable for applications with high contact frequency. Due to the compact and easy-mounted design of the sensor as well as the contact-free function, the sensor is normally not subjected to mechanical wear.
Learn more about Inxpect radar systems. The worlds first SIL 2/PL d certified, radar-based safety system for use around hazardous machinery.
Whether you're working with opaque materials or transparent items like glass or plastic, these sensors deliver reliable performance across a wide range of applications.
OEM Automatics Safety Experts guide you through the process of setting up your light curtains & barriers, to protect your people and equipment.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
New signal lights from Auer Signal are now available! The first products to be launched in this series are the Smart Dot 50 in the Basic and Standard versions, as well as the Smart Indicator 50 in the Basic version.Â
LIDAR, Radar, and Laser scanners are all powerful technologies used to enhance safety in industrial and automated environments. But how do you choose the right one for your application?
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Cable length | Electrical connection | Mounting | Output | Sensing distance | Weight | Price | ||
---|---|---|---|---|---|---|---|---|---|
![]()
95B063821 M30 Inductive Flush 15mm PNP NO/NC 2m Cable
Art:
IS-30-G5-03
Copied
|
2000 mm
|
Embedded 2m cable
|
Flush
|
PNP, NO, NC
|
15 mm
|
210 g
|
| ||
![]()
95B064400 M30 Inductive Flush 15mm NPN NO+NC 2m Cable
Art:
IS-30-G6-03
Copied
|
2000 mm
|
Embedded 2m cable
|
Flush
|
NPN, NO, NC
|
15 mm
|
210 g
|
| ||
![]()
95B064430 M30 Inductive Flush 15mm NPN NO+NC M12 Connector
Art:
IS-30-G6-S2
Copied
|
|
M12 4-pin connector
|
Flush
|
NPN, NO, NC
|
15 mm
|
170 g
|
| ||
![]()
95B064410 M30 Inductive Non Flush 20mm NPN NO+NC 2m Cable
Art:
IS-30-H6-03
Copied
|
2000 mm
|
Embedded 2m cable
|
Non-flush
|
NPN, NO, NC
|
20 mm
|
210 g
|
| ||
![]()
95B064440 M30 Inductive Non-Flush 20mm NPN NO/NC M12 Connect
Art:
IS-30-H6-S2
Copied
|
|
M12 4-pin connector
|
Non-flush
|
NPN, NO, NC
|
20 mm
|
170 g
|
|
Select a variant in the list
