DUELCO
Duelco - NST-2007F Safety Relay
One of the most common relays in our safety relay range. Suitable for most applications.
- Safety Category 4 (PLe)
- 3 NO safety outputs
- 1 NC status output
- Status-/fault indication via LEDs
- Short circuit monitoring
Selected variant
Technical data
| IP class connection | IP20 |
|---|---|
| IP class housing | IP40 |
| PL | e (EN ISO 13849-1) |
| Reset type | Automatic/manual |
| Safety category | 4 |
| Safety outputs NO | 3 |
| Signal output NC | 1 |
|---|---|
| Supply voltage ac max | 230 V AC |
| Temperature operational max | 50 °C |
| Temperature operational min | -25 °C |
| Width | 22.5 mm |
Product description
One of the most common relays in our safety relay range. Suitable for most applications.
