Selected variant
Technical data
| Approvals | CE |
|---|---|
| In compliance with | EMC, LVD, MD |
| IP class | IP67 |
| Material of body | PBT, PMMA |
| Output | PNP |
| Range | 0-8 m |
| Reaction time | 1 ms |
| Sensing distance | 8 m |
| Storage temperature max | 70 °C |
|---|---|
| Storage temperature min | -25 °C |
| Supply voltage | 24 V DC |
| Temperature operational max | 55 °C |
| Temperature operational min | -25 °C |
| Type of light | IR LED |
| Voltage tolerance | ±15 % |
