Datasensing SH4-Body Base Safety Light Curtain
Datasensing’s SH4-BODY safety light curtain is designed for body/pedestrian access.
The maximum distance between the emitter and receiver is 70m.
SH4 Safety light curtains do not have a dead zone at the top or bottom of the emitter/receiver.
- Body detection, Type 4, PL e
- Operating distance: 70 m
- Temperature range: -30...+55 °C
- Basic functions, 2x OSSD Safety Outputs
Selected variant
Technical data
| Function | Automatic restart |
|---|---|
| IP class | IP65, IP67 |
| Material of body | Aluminium |
| MTTFd | 43 year(s) |
| Number of beams | 2 |
| PL | e |
| Protection height | 500 mm |
| Reaction time | 12 ms |
|---|---|
| Sensing distance | 15 / 70m |
| SIL | 3 |
| Supply voltage | 24 V DC |
| Weight | 1.4 Kg/mt (single bar) |
| Voltage tolerance | ± 20% |
Product description
Datasensing’s SH4-BODY safety light curtain is designed for body/pedestrian access.
The maximum distance between the emitter and receiver is 70m.
SH4 Safety light curtains do not have a dead zone at the top or bottom of the emitter/receiver.
