DUOmetric
The light curtains control a defined surveillance area with several invisible, infrared light beams. The curtain photocells consist of a transmitter and a receiver in thin anodized aluminum profile and an external control unit. They work according to the principle of evaluating each individual beam detected by the external control unit. As a result, complex measurement tasks can be carried out and the control unit activates the corresponding outputs and digital data transmission.
Beam spacing max | 112 mm |
---|---|
Beam spacing min | 2.5 mm |
Controller | LVB, LVE, LVX |
Detection height | 5812 mm |
Detection method | Parallella / parallella och diagonala strålar |
IP class | IP20, IP54, IP65 |
Light type | IR-LED 880 nm |
Monitoring height min | 35 mm |
---|---|
Power consumption | 3,1 W |
Range Area 1 max | 6 m |
Range Area 1 min | 0.4 m |
Temperature range | -30 till +55°C |
The light curtains control a defined surveillance area with several invisible, infrared light beams. The curtain photocells consist of a transmitter and a receiver in thin anodized aluminum profile and an external control unit. They work according to the principle of evaluating each individual beam detected by the external control unit. As a result, complex measurement tasks can be carried out and the control unit activates the corresponding outputs and digital data transmission.
New signal lights from Auer Signal are now available! The first products to be launched in this series are the Smart Dot 50 in the Basic and Standard versions, as well as the Smart Indicator 50 in the Basic version.
Optimise your production line with encoders, inclinometers, displays and slip rings
Designed for high-performance safety applications such as material handling, conveyors, robotics, and system integration. OEM Automatic is excited to announce its latest supplier partnership with Hokuyo
Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.
Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.
ATEX ensures that both equipment and work processes are designed to minimize these risks and create a safe working environment.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Beam spacing max | Beam spacing min | Controller | Detection height | Detection method | IP class | Light type | Monitoring height min | Number of beams | Per beam cycle time | Power consumption | Profile pairs | Range Area 1 max | Range Area 1 min | Supply voltage | Temperature range | Price | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
112 mm
|
2.5 mm
|
LVB, LVE, LVX
|
5812 mm
|
Parallella / parallella och diagonala strålar
|
IP20, IP54, IP65
|
IR-LED 880 nm
|
35 mm
|
|
|
3,1 W
|
|
6 m
|
0.4 m
|
|
-30 till +55°C
|
| |||
112 mm
|
2.5 mm
|
FAW
|
5812 mm
|
|
IP20, IP54, IP65
|
IR-LED 880 nm
|
35 mm
|
|
|
|
|
6 m
|
0.4 m
|
|
-20 °C till +40 °C
|
| |||
|
|
|
|
|
IP00
|
|
|
max 500 fysiska / max 1200 logiska
|
från 30 μs
|
4,2 W
|
1 Pair
|
|
|
24 VDC (18 till 30 VDC) /5 % ripple
|
-25 till +40°C
|
| |||
|
|
|
|
|
IP00
|
|
|
max 500 fysiska / max 1200 logiska
|
från 30 μs
|
4,2 W
|
2 Pair
|
|
|
24 VDC (18 till 30 VDC) /5 % ripple
|
-25 till +40°C
|
| |||
|
|
|
|
|
IP20
|
|
|
max 700 fysiska / max 700 logiska
|
från 6 μs
|
4,5 W
|
1 Pair
|
|
|
24 VDC (18 till 30 VDC) /5 % ripple
|
0 till +40°C
|
|
Select a variant in the list
