AUER SIGNAL
Strong well-designed horn for use in areas exposed to explosions in zones 1 and 2.
The housing is made of impact resistant synthetic material.
Insulation class ll.
DC models with electronic switch.
| Housing Colour | Black |
|---|---|
| IP class | IP54 |
| Nominal current max | 0.15 A |
| Nominal current min | 0.15 A |
| Number of tones | 1 Â |
| Sound level max | 108 dB |
| Sound level min | 108 dB |
| Supply voltage ac max | 122.5 V AC |
|---|---|
| Supply voltage ac min | 103.5 V AC |
| Temperature operational max | 60 °C |
| Temperature operational min | -20 °C |
| Terminal connection | 2.5 mm² |
| Weight | 500 g |
Strong well-designed horn for use in areas exposed to explosions in zones 1 and 2.
The housing is made of impact resistant synthetic material.
Insulation class ll.
DC models with electronic switch.
Have you ever wondered if there's any difference between cable coils and cable reels?
Our cable experts take you through the advantages of using cable coils.
What tri-rated cable are you currently using? Does the product or service you receive leave you wanting more? It’s time to ask the question. Because now, you’ve got options.
This innovative push-in connection system enables time savings of up to 50%, whether you're wiring control panels or managing complex installations
Solar energy has become a pillar of the global energy transition. The experts at OEM Automatic have broken down the role of photovoltaic fuses and their contribution to solar systems, as well as, how to choose the right solution for you.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
Do you need reliable protection for measuring and control equipment? DEHN YellowLine delivers voltage surge protection tailored for building, measuring, and control systems
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Nominal current max | Nominal current min | Supply voltage ac max | Supply voltage ac min | Supply voltage dc max | Supply voltage dc min | Price | ||
|---|---|---|---|---|---|---|---|---|---|
Ex/ATEX Signal horn, 110 V ac, MHPT
Art:
301100110
Copied
|
0.15 A
|
0.15 A
|
122.5 V AC
|
103.5 V AC
|
|
|
|
||
|
Ex/ATEX Signal horn, 230 V ac, MHPT
Art:
301100113
Copied
|
0.07 A
|
0.07 A
|
253 V AC
|
207 V AC
|
|
|
|
||
|
Ex/ATEX Signal horn, 24 V dc, MHPT
Art:
301100005
Copied
|
0.3 A
|
0.3 A
|
|
|
26.4 V DC
|
21.6 V DC
|
|
Select a variant in the list
