SENSATA CRYDOM
Ratings from 10A to 30A @ 660 VAC - Slim 22.5mm (width) package - SCR output for heavy industrial loads - LED input status indicator - AC or DC control - zero voltage (resistive loads) or instantaneous turn on (inductive loads) output
Â
Overview |
|
---|---|
Output current | 10 A |
Output voltage | 48-660V ac |
Control voltage | 4-32V dc |
Connection | Screw connection |
Type of control | Zero voltage turn on |
Additional features | N/A |
Output voltage | 48-660V ac |
Output Specification |
|
Number of poles | 1 |
Control voltage | 4-32V dc |
General Specification |
|
---|---|
Temperature operational min | -40 °C |
Temperature operational max | 80 °C |
Storage temperature max | 125 °C |
Storage temperature min | -40 °C |
Weight | 280 g |
Height | 81.9 mm |
Width | 22.5 mm |
Depth | 99 mm |
Ratings from 10A to 30A @ 660 VAC - Slim 22.5mm (width) package - SCR output for heavy industrial loads - LED input status indicator - AC or DC control - zero voltage (resistive loads) or instantaneous turn on (inductive loads) output
Â
This innovative push-in connection system enables time savings of up to 50%, whether you're wiring control panels or managing complex installations
Solar energy has become a pillar of the global energy transition. The experts at OEM Automatic have broken down the role of photovoltaic fuses and their contribution to solar systems, as well as, how to choose the right solution for you.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
Do you need reliable protection for measuring and control equipment? DEHN YellowLine delivers voltage surge protection tailored for building, measuring, and control systems
Choosing the right circuit breaker is important for protecting DC circuits. Two primary forms of protection are MCBs and ECBs. The experts at OEM Automatic breakdown the two circuit breakers for you!
New signal lights from Auer Signal are now available! The first products to be launched in this series are the Smart Dot 50 in the Basic and Standard versions, as well as the Smart Indicator 50 in the Basic version.Â
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Parts | Output current | Type of control | Additional features | Control voltage | Price | ||
---|---|---|---|---|---|---|---|
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 4.5-32V dc In, ZC
Art:
CKRD6010
Copied
|
10 A
|
Zero voltage turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 4.5-32V dc In, Inst.
Art:
CKRD6010-10
Copied
|
10 A
|
Instantaneous turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 4.5-32V dc In, ZC IOP
Art:
CKRD6010P
Copied
|
10 A
|
Zero voltage turn on
|
Overvoltage protection included
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 4.5-32V dc In, ZC
Art:
CKRD6020
Copied
|
20 A
|
Zero voltage turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 4.5-32V dc In, Inst.
Art:
CKRD6020-10
Copied
|
20 A
|
Instantaneous turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 4.5-32V dc In, ZC IOP
Art:
CKRD6020P
Copied
|
20 A
|
Zero voltage turn on
|
Overvoltage protection included
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 4.5-32V dc In, ZC
Art:
CKRD6030
Copied
|
30 A
|
Zero voltage turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 4.5-32V dc In, Inst.
Art:
CKRD6030-10
Copied
|
30 A
|
Instantaneous turn on
|
N/A
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 4.5-32V dc In, ZC IOP
Art:
CKRD6030P
Copied
|
30 A
|
Zero voltage turn on
|
Overvoltage protection included
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 4.5-32V dc In, Inst.
Art:
CKRD6030P-10
Copied
|
30 A
|
Instantaneous turn on
|
Overvoltage protection included
|
4-32V dc
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 90-140V ac In, ZC
Art:
CKRB6010
Copied
|
10 A
|
Zero voltage turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 90-140V ac In, Inst.
Art:
CKRB6010-10
Copied
|
10 A
|
Instantaneous turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 90-140V ac In, ZC IOP
Art:
CKRB6010P
Copied
|
10 A
|
Zero voltage turn on
|
Overvoltage protection included
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 90-140V ac In, ZC
Art:
CKRB6020
Copied
|
20 A
|
Zero voltage turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 90-140V ac In, Inst.
Art:
CKRB6020-10
Copied
|
20 A
|
Instantaneous turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 90-140V ac In, ZC IOP
Art:
CKRB6020P
Copied
|
20 A
|
Zero voltage turn on
|
Overvoltage protection included
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 90-140V ac In, ZC
Art:
CKRB6030
Copied
|
30 A
|
Zero voltage turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 90-140V ac In, Inst.
Art:
CKRB6030-10
Copied
|
30 A
|
Instantaneous turn on
|
N/A
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 90-140V ac In, ZC IOP
Art:
CKRB6030P
Copied
|
30 A
|
Zero voltage turn on
|
Overvoltage protection included
|
90-140V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 110-280V ac In, ZC
Art:
CKRA6030
Copied
|
30 A
|
Zero voltage turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 110-280V ac In, ZC
Art:
CKRA6010
Copied
|
10 A
|
Zero voltage turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 110-280V ac In, Inst.
Art:
CKRA6010-10
Copied
|
10 A
|
Instantaneous turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 18-36V ac In, ZC
Art:
CKRA6010E
Copied
|
10 A
|
Zero voltage turn on
|
N/A
|
18-36V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 10A, 110-280V ac In, ZC IOP
Art:
CKRA6010P
Copied
|
10 A
|
Zero voltage turn on
|
Overvoltage protection included
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 110-280V ac In, ZC
Art:
CKRA6020
Copied
|
20 A
|
Zero voltage turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 110-280V ac In, Inst.
Art:
CKRA6020-10
Copied
|
20 A
|
Instantaneous turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 18-36V ac In, ZC
Art:
CKRA6020E
Copied
|
20 A
|
Zero voltage turn on
|
N/A
|
18-36V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 20A, 110-280V ac In, ZC IOP
Art:
CKRA6020P
Copied
|
20 A
|
Zero voltage turn on
|
Overvoltage protection included
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 110-280V ac In, Inst.
Art:
CKRA6030-10
Copied
|
30 A
|
Instantaneous turn on
|
N/A
|
110-280V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 18-36V ac In, ZC
Art:
CKRA6030E
Copied
|
30 A
|
Zero voltage turn on
|
N/A
|
18-36V ac
|
| ||
![]()
DIN Rail SSR 22.5mm 660V ac 30A, 110-280V ac In, ZC IOP
Art:
CKRA6030P
Copied
|
30 A
|
Zero voltage turn on
|
Overvoltage protection included
|
110-280V ac
|
|
