LUMEL
N24
Universal input digital panel meter for measurement of d.c. voltage or d.c. current, temperature from Pt100 sensors and J, K thermocouples, a.c. voltage and a.c. current.
- Universal input (Programmable)
- Wide voltage, AC/DC control
- 4 Digit LED display
Selected variant
Technical data
| Additional functions | Rescaling |
|---|---|
| Digit height | 20 mm |
| Dimensions | 96 x 48 x 64 mm Panel cut-out: 92+0,6 45+0,6 mm |
| Display | Yes |
| Input type | ±100V dc |
| IP class | IP65 |
| Mounting | Panel mount |
| Number of digits | 4 |
|---|---|
| Supply voltage | 240 V ac |
| Temperature operational max | 55 °C |
| Temperature operational min | -10 °C |
| Weight | 0.25 kg |
Ordering information
Please refer to the image below for ordering information.
 **Part numbers have changed from ending with E0 to M0, please be advised any part numbers below that end in E0 may say M0 in the datasheet. The product is the same.**
