Selected variant
Technical data
| Approvals | CE, RoHS |
|---|---|
| Breaking Voltage | 250 V |
| Contact material | AgNi |
| Inrush max | 15 A |
| IP class | IP20 |
| Measurement range | 0,1-5A |
| Nominal current | 6 A |
| Number of contacts | 1 |
| Power consumption | 1.6 W |
| Recommended tightening torque | 0.4 |
|---|---|
| Storage temperature max | 85 °C |
| Storage temperature min | -40 °C |
| Temperature operational max | 60 °C |
| Temperature operational min | -40 °C |
| Weight | 107 g |
| Voltage ac/dc max | 48 V |
| Voltage ac/dc min | 12 V |
