Selected variant
Technical data
Input Data |
|
|---|---|
| Input current max | 10 A |
| Operating voltage dc min | 10 V |
| Operating voltage dc max | 32 V |
| Power through distribution beam max | 40 A |
Output Data |
|
| Output current max | 10 A |
| Adjustable current min | 1 A |
| Adjustable current max | 10 A |
| Adjustable steps | 1 A |
| Voltage drop over semiconductor | 170 mV |
| Capacitance max | 10000 µF |
Dimensions |
|
| Width | 8.1 mm |
*Invisible Heading* |
|
|---|---|
| Depth | 116 mm |
| Height | 114.5 mm |
Connection Data |
|
| Cross section min | 0.25 mm² |
| Cross section max | 2.5 mm² |
| IP class | IP20 |
Approvals |
|
| Approvals | CE, cULus, GL |
| EMC | EN61000-6-2, EN61000-6-3 |
Additional data |
|
| Temperature operational min | -25 °C |
| Temperature operational max | 50 °C |
| Weight | 120 g |
