Isoflexx® busbar can be bent into acute angles and has a small bending radius; this saves space in the enclosures.
Without the need for extra fixings, ISOFLEXX can be easily bolted to main busbars.
Available in lengths of 250mm to 2000mm as standard.
Isoflexx® busbar can also be customised, including cutting, bending and drilled/punched as required.
Insulation: high quality PVC or halogen free silicon
UL/CSA approved
Volatge Rating - 1000VAC/1500VDC according to IEC 61439-1. 600VAC/750VDC According to UL
.
General Data |
|
|---|---|
| Colour | Black |
| Cross section | 21.6 mm² |
| Current at ΔT 50°C | 130 A |
| Approvals | UL, CSA, CE, RoHS, EN50525 |
| Insulation material | Self-closing rigid PVC |
Dimensions |
|
| Length | 2000 mm |
| Thickness | 0.8 mm |
*Invisible Heading* |
|
|---|---|
| Width | 9 mm |
Ampacity |
|
| Current at ΔT 30°C | 98 A |
Additional Data |
|
| Tinned | No |
| Number of laminates | 3 |
| Dielectric strength | 20 kV/m |
| Weight | 0.384 kg |
Isoflexx® busbar can be bent into acute angles and has a small bending radius; this saves space in the enclosures.
Without the need for extra fixings, ISOFLEXX can be easily bolted to main busbars.
Available in lengths of 250mm to 2000mm as standard.
Isoflexx® busbar can also be customised, including cutting, bending and drilled/punched as required.
Insulation: high quality PVC or halogen free silicon
UL/CSA approved
Volatge Rating - 1000VAC/1500VDC according to IEC 61439-1. 600VAC/750VDC According to UL
.
Have you ever wondered if there's any difference between cable coils and cable reels?
Our cable experts take you through the advantages of using cable coils.
What tri-rated cable are you currently using? Does the product or service you receive leave you wanting more? It’s time to ask the question. Because now, you’ve got options.
This innovative push-in connection system enables time savings of up to 50%, whether you're wiring control panels or managing complex installations
Solar energy has become a pillar of the global energy transition. The experts at OEM Automatic have broken down the role of photovoltaic fuses and their contribution to solar systems, as well as, how to choose the right solution for you.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
Do you need reliable protection for measuring and control equipment? DEHN YellowLine delivers voltage surge protection tailored for building, measuring, and control systems
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Cross section | Current at ΔT 50°C | Approvals | Thickness | Width | Current at ΔT 30°C | Number of laminates | Weight | Price | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
Classic, 3 x 9 x 0.8 - 130 A
Art:
11311000
Copied
|
21.6 mm²
|
130 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
9 mm
|
98 A
|
3
|
0.384 kg
|
|
||
|
Classic, 6 x 9 x 0.8 - 196 A
Art:
11311020
Copied
|
43.2 mm²
|
196 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
9 mm
|
147 A
|
6
|
0.769 kg
|
|
||
|
Classic, 9 x 9 x 0.8 - 238 A
Art:
11311420
Copied
|
64.8 mm²
|
238 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
9 mm
|
179 A
|
9
|
1.153 kg
|
|
||
|
Classic, 3 x 13 x 0.5 - 144 A
Art:
11311030
Copied
|
19.5 mm²
|
144 A
|
UL, CSA, CE, RoHS, EN50525
|
0.5 mm
|
13 mm
|
108 A
|
3
|
0.347 kg
|
|
||
|
Classic, 6 x 13 x 0.5 - 215A
Art:
11311040
Copied
|
39 mm²
|
215 A
|
UL, CSA, CE, RoHS, EN50525
|
0.5 mm
|
13 mm
|
162 A
|
6
|
0.694 kg
|
|
||
|
Classic, 4 x 15.5 x 0.8 - 267 A
Art:
11311060
Copied
|
49.6 mm²
|
267 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
16 mm
|
201 A
|
4
|
0.883 kg
|
|
||
|
Classic, 6 x 15.5 x 0.8 - 335 A
Art:
11311070
Copied
|
74.4 mm²
|
335 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
16 mm
|
252 A
|
6
|
1.324 kg
|
|
||
|
Classic, 10 x 15.5 x 0.8 - 439 A
Art:
11311080
Copied
|
124 mm²
|
439 A
|
UL, CSA, CE, RoHS, EN50525
|
0.8 mm
|
16 mm
|
330 A
|
10
|
2.207 kg
|
|
||
|
Classic, 2 x 20 x 1 - 250 A
Art:
11311550
Copied
|
40 mm²
|
250 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
188 A
|
2
|
0.712 kg
|
|
||
|
Classic, 3 x 20 x 1 - 315 A
Art:
11311560
Copied
|
60 mm²
|
315 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
237 A
|
3
|
1.068 kg
|
|
||
|
Classic, 4 x 20 x 1 - 370 A
Art:
11311570
Copied
|
80 mm²
|
370 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
278 A
|
4
|
1.424 kg
|
|
||
|
Classic, 5 x 20 x 1 - 424 A
Art:
11311580
Copied
|
100 mm²
|
424 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
319 A
|
5
|
1.78 kg
|
|
||
|
Classic, 6 x 20 x 1 - 472 A
Art:
11311590
Copied
|
120 mm²
|
472 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
355 A
|
6
|
2.136 kg
|
|
||
|
Classic, 10 x 20 x 1 - 661 A
Art:
11311600
Copied
|
200 mm²
|
661 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
20 mm
|
497 A
|
10
|
3.56 kg
|
|
||
|
Classic, 2 x 24 x 1 - 267 A
Art:
11311530
Copied
|
48 mm²
|
267 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
201 A
|
2
|
0.854 kg
|
|
||
|
Classic, 3 x 24 x 1 - 367 A
Art:
11311440
Copied
|
72 mm²
|
367 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
276 A
|
3
|
1.282 kg
|
|
||
|
Classic, 4 x 24 x 1 - 428 A
Art:
11311450
Copied
|
96 mm²
|
428 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
322 A
|
4
|
1.709 kg
|
|
||
|
Classic, 5 x 24 x 1 - 469A
Art:
11311460
Copied
|
120 mm²
|
491 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
369 A
|
5
|
2.136 kg
|
|
||
|
Classic, 6 x 24 x 1 - 541 A
Art:
11311470
Copied
|
144 mm²
|
541 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
407 A
|
6
|
2.563 kg
|
|
||
|
Classic, 8 x 24 x 1 - 642 A
Art:
11311480
Copied
|
192 mm²
|
642 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
483 A
|
8
|
3.418 kg
|
|
||
|
Classic, 10 x 24 x 1 - 743 A
Art:
11311490
Copied
|
240 mm²
|
743 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
24 mm
|
559 A
|
10
|
4.272 kg
|
|
||
|
Classic, 2 x 32 x 1 - 384 A
Art:
11311360
Copied
|
64 mm²
|
384 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
289 A
|
2
|
1.139 kg
|
|
||
|
Classic, 3 x 32 x 1 - 477 A
Art:
11311370
Copied
|
96 mm²
|
477 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
359 A
|
3
|
1.709 kg
|
|
||
|
Classic, 4 x 32 x 1 - 556 A
Art:
11311500
Copied
|
128 mm²
|
556 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
418 A
|
4
|
2.278 kg
|
|
||
|
Classic, 5 x 32 x 1 - 634 A
Art:
11311430
Copied
|
160 mm²
|
634 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
477 A
|
5
|
2.848 kg
|
|
||
|
Classic, 6 x 32 x 1 - 700 A
Art:
11311510
Copied
|
192 mm²
|
700 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
526 A
|
6
|
3.418 kg
|
|
||
|
Classic, 8 x 32 x 1 - 829 A
Art:
11311520
Copied
|
256 mm²
|
829 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
623 A
|
8
|
4.557 kg
|
|
||
|
Classic, 10 x 32 x 1 - 959 A
Art:
11311390
Copied
|
320 mm²
|
959 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
32 mm
|
721 A
|
10
|
5.696 kg
|
|
||
|
Classic, 5 x 40 x 1 - 762 A
Art:
11311130
Copied
|
200 mm²
|
762 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
40 mm
|
573 A
|
5
|
3.56 kg
|
|
||
|
Classic, 8 x 40 x 1 - 983 A
Art:
11311140
Copied
|
320 mm²
|
983 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
40 mm
|
739 A
|
8
|
5.696 kg
|
|
||
|
Classic, 10 x 40 x 1 - 1131 A
Art:
11311150
Copied
|
400 mm²
|
1131 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
40 mm
|
850 A
|
10
|
7.12 kg
|
|
||
|
Classic, 5 x 50 x 1 - 927 A
Art:
11311160
Copied
|
250 mm²
|
927 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
50 mm
|
697 A
|
5
|
4.45 kg
|
|
||
|
Classic, 8 x 50 x 1 - 1185 A
Art:
11311170
Copied
|
400 mm²
|
1185 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
50 mm
|
891 A
|
8
|
7.12 kg
|
|
||
|
Classic, 10 x 50 x 1 - 1357 A
Art:
11311180
Copied
|
500 mm²
|
1357 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
50 mm
|
1020 A
|
10
|
8.9 kg
|
|
||
|
Classic, 5 x 63 x 1 - 1099 A
Art:
11311190
Copied
|
315 mm²
|
1099 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
63 mm
|
826 A
|
5
|
5.607 kg
|
|
||
|
Classic, 6 x 63 x 1 - 1253 A
Art:
11311610
Copied
|
378 mm²
|
1253 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
63 mm
|
942 A
|
6
|
6.728 kg
|
|
||
|
Classic, 8 x 63 x 1 - 1361 A
Art:
11311200
Copied
|
504 mm²
|
1361 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
63 mm
|
1038 A
|
8
|
8.971 kg
|
|
||
|
Classic, 10 x 63 x 1 - 1569 A
Art:
11311210
Copied
|
630 mm²
|
1569 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
63 mm
|
1180 A
|
10
|
11.214 kg
|
|
||
|
Classic, 4 x 80 x 1 - 1269 A
Art:
11311650
Copied
|
320 mm²
|
1269 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
80 mm
|
954 A
|
4
|
5.7 kg
|
|
||
|
Classic, 5 x 80 x 1 - 1269 A
Art:
11311220
Copied
|
400 mm²
|
1423 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
80 mm
|
1070 A
|
5
|
7.12 kg
|
|
||
|
Classic, 6 x 80 x 1 - 1537 A
Art:
11311660
Copied
|
480 mm²
|
1537 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
80 mm
|
1156 A
|
6
|
7.12 kg
|
|
||
|
Classic, 8 x 80 x 1 - 1766 A
Art:
11311230
Copied
|
640 mm²
|
1766 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
80 mm
|
1328 A
|
8
|
11.39 kg
|
|
||
|
Classic, 10 x 80 x 1 - 1995 A
Art:
11311240
Copied
|
800 mm²
|
1995 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
80 mm
|
1500 A
|
10
|
14.24 kg
|
|
||
|
Classic, 5 x 100 x 1 - 1729 A
Art:
11311250
Copied
|
500 mm²
|
1729 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
100 mm
|
1300 A
|
5
|
8.9 kg
|
|
||
|
Classic, 8 x 100 x 1 - 2136 A
Art:
11311260
Copied
|
800 mm²
|
2136 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
100 mm
|
1606 A
|
8
|
14.24 kg
|
|
||
|
Classic, 10 x 100 x 1 - 2407 A
Art:
11311270
Copied
|
1000 mm²
|
2407 A
|
UL, CSA, CE, RoHS, EN50525
|
1 mm
|
100 mm
|
1810 A
|
10
|
17.8 kg
|
|
||
|
Classic, 12 x 100 x 1 - 2625 A
Art:
11311280
Copied
|
1200 mm²
|
2625 A
|
|
1 mm
|
100 mm
|
1974 A
|
12
|
21.36 kg
|
|
Select a variant in the list
