AUER SIGNAL

G Series, Xenon Strobe Beacon, Ø120mm

The Series G is AUERs best-value solution for universal applications. The large signal lamp with 48 LEDs produces an excellent frontal and lateral signal effect. The surface-mounted beacon series is available in the size Ø 120 mm with a low calotte. With an ingress protection class of IP65, the G series surface-mounted beacon is recommended for outdoor use.



Mounting options include vertical mounting, this model also contains a bayonet locking system with push button. It is used for general applications due to its attractive price to performance ratio.



Read more
  • Ø120mm Beacon
  • Strobe, Flashing and Steady light options
  • Wide control voltage range

Selected variant

Available in several variants

Selected variant

Technical data

General data

Lens colour Orange
Light type Strobe
Light source Xenon
Housing Colour Black RAL 9005

Rated operating conditions

Nominal Supply Voltage 230-240 V AC
Nominal current 100 mA
Flash energy 5 J

*Invisible Heading*

Flash frequency 1 Hz
Operational temperature -30°C ... 50°C
Terminal connection 2.5 mm²

Dimensions

Height 102 mm
Diameter 120 mm

Additional data

IP class IP65

Measurements and connections

Technical illustrations

Product description

The Series G is AUERs best-value solution for universal applications. The large signal lamp with 48 LEDs produces an excellent frontal and lateral signal effect. The surface-mounted beacon series is available in the size Ø 120 mm with a low calotte. With an ingress protection class of IP65, the G series surface-mounted beacon is recommended for outdoor use.



Mounting options include vertical mounting, this model also contains a bayonet locking system with push button. It is used for general applications due to its attractive price to performance ratio.
