INDUSTRILÅS
Vector T3 handle
Flat compression Vector 3 T-handle with 4 mm compression stroke. Sealed to IP65 against water and dust. Four blind-mounted studs and PUR gasket ensure watertight installation.
Available with fixed or adjustable roller cams, as well as 1-, 2- and 3-point locking options. Vector T3 comes in zinc or stainless steel. The zinc version offers a zinc pivot handle with a cast steel shaft for excellent strength. The stainless version with T-handle and pivot shaft in polished stainless steel is recommended for applications used in harsh environments. Available with or without the rotatable dust cover.
- IP65
- Door thickness 10mm
- Zinc/stainless steel
- 4mm compression
- Adjustable
Selected variant
Vector T3 handle, mechan, keyed alike 751, SS304/303, black, 90°
Art:
Selected variant
Technical data
Product description
Flat compression Vector 3 T-handle with 4 mm compression stroke. Sealed to IP65 against water and dust. Four blind-mounted studs and PUR gasket ensure watertight installation.
Available with fixed or adjustable roller cams, as well as 1-, 2- and 3-point locking options. Vector T3 comes in zinc or stainless steel. The zinc version offers a zinc pivot handle with a cast steel shaft for excellent strength. The stainless version with T-handle and pivot shaft in polished stainless steel is recommended for applications used in harsh environments. Available with or without the rotatable dust cover.
