NAFSA
NAFSA - CU20 CP series
These locking bolts are based on simple linear solenoids, with a reinforced shaft to cope with high lateral loadings.
They lock under no voltage for passive security, feature front and rear mountings and a anti rotation bolt.
- Security locking bolt
- Class E winding (120ºC)
- Locks without power
- Up to 1.75N force
- Customer specific version available
Selected variant
Technical data
| Absorbed power @ 20°C, 100% duty | 4.2 W |
|---|---|
| Absorbed power @ 20°C, 25% duty | 17 W |
| Duty cycle | 100 % |
| Insulation class | E(120ºC) |
| IP class | IP40 |
| Max radial force using body mount | 2000 N |
| Max radial force using frontal fixing | 750 N |
| Plunger weight | 17 g |
| Return spring force | 1.5 N |
|---|---|
| Stroke | 7 mm |
| Temperature rise | 70 °C |
| Total weight | 107 g |
| Voltage dc max | 48 V |
| Voltage dc min | 12 V |
Product description
These locking bolts are based on simple linear solenoids, with a reinforced shaft to cope with high lateral loadings.
They lock under no voltage for passive security, feature front and rear mountings and a anti rotation bolt.
