Sugatsune

AS-HG Lift Assist Hinge

The Sugatsune AS-HG-PA300 Lift Assist Hinge is a surface-mounted, stainless-steel hinge with adjustable spring torque and an integrated damper for smooth, controlled motion, making it ideal for heavy top-opening lids. Designed for use in various applications it ensures precise motion control and durability under varying conditions.
  • Stainless Steel Hinge
  • Stainless Steel Brackets
  • Grey Plastic Cover
  • Plastic Slider
  • Steel Springs

Selected variant

AS-HG Main Image.jpg

Parts Set For Lift Assist Hinges

Art:

Selected variant

Technical data

Material Stainless steel, Steel, POM, PBT
Operating Range Free up to 110°, assisted up to 90° and with soft close
Surface finish Barrel Polished Brackets
Torque 9±10%
Weight 800 g

Measurements and connections

Product description

The Sugatsune AS-HG-PA300 Lift Assist Hinge (model HG-PA300-15) is a precision-engineered, balance-adjustable hinge designed to facilitate the effortless lifting of heavy, top-opening lids. Constructed from durable 430 stainless steel with a light grey finish, this external surface-mounted hinge features a spring-assisted mechanism that delivers a peak torque of 15 Nm within an optimal opening range of 60° to 80°. The torque is adjustable within ±10% via an integrated adjustment screw, allowing customisation to accommodate varying lid weights and sizes. Additionally, the built-in damper ensures a soft-close function, preventing lids from slamming shut and enhancing safety in high-precision environments. The hinge measures 278 mm in length, 180 mm in width, and 63 mm in height, and weighs approximately 3.4 kg.

This hinge is particularly suited for applications requiring controlled lid movement, such as in medical equipment, analytical instruments, and semiconductor machinery. Its robust construction and adjustable torque make it ideal for environments where precise motion control is critical. The HG-PA300-15's design ensures consistent performance across a range of temperatures, making it a reliable choice for various industrial applications.
