Selected variant
Technical data
| Aperture range max (f) | 2.5 |
|---|---|
| Diameter | 52 mm |
| Distortion | 0.84 |
| Filter | 46 |
| Focal length | 18 mm |
| Focus | Manual |
| Focus distance min | 120 mm |
| Iris | Manual iris |
| Length | 66.8 mm |
|---|---|
| Lens Barrel | C-Mount |
| Pixel size min | 2.7 µm |
| Resolution max | 25 MP |
| Sensor size max | 4/3" |
| Type of lens | Standard |
