AZURE PHOTONICS
Azure 1.0 2MP fixed focal lenses
1", 2MP
- Sensor Size: 1"
- Focal lengths up to 75mm
- Resolution: 2 Megapixel
- C-Mount
Selected variant
Technical data
| Aperture range max (f) | 2 |
|---|---|
| Aperture range min | 16 |
| Distortion | -2.8 |
| Focal length | 4 mm |
| Focus | Manual |
| Focus distance min | 100 mm |
| Iris | Manual iris |
| Lens Barrel | C-Mount |
|---|---|
| Pixel size min | 5 µm |
| Resolution max | 2 MP |
| Sensor size max | 1/2" |
| Type of lens | Standard |
| Weight | 0.13 kg |
