Oriental Motor Unipolar 5 or 6-Wire PKP Series Hybrid Stepper Motor PKP213U05A

Configuration	Single Shaft
Frame size	20 mm
Inductance	2.9 mH/Phase
Maximum Holding Torque	0.014 Nm
Number of phases	2
Number of Wires	5
Rated Current	0.5 A/Phase

Rotor Inertia	1.6 x 10⁻⁷
Step angle	1.8 °
Type	Standard
Weight	0.05 kg
Winding Resistance	8.5 Ω/Phase
Voltage	4.25 V DC

Parts	Configuration	Frame size	Inductance	Maximum Holding Torque	Number of Wires	Rated Current	Rotor Inertia	Weight	Winding Resistance	Voltage
PKP Series stepper motor, 2-Phase, 20mm frame, 5 or 6 leads, single shaft Art: PKP213U05A Copied	Single Shaft	20 mm	2.9 mH/Phase	0.014 Nm	5	0.5 A/Phase	1.6 x 10⁻⁷	0.05 kg	8.5 Ω/Phase	4.25 V DC
PKP Series stepper motor, 2-Phase, 20mm frame, 5 or 6 leads, double shaft Art: PKP213U05B Copied	Double Shaft	20 mm	2.9 mH/Phase	0.014 Nm	5	0.5 A/Phase	1.6 x 10⁻⁷	0.05 kg	8.5 Ω/Phase	4.25 V DC
PKP Series stepper motor, 2-Phase, 20mm frame, 5 or 6 leads, single shaft Art: PKP214U06A Copied	Single Shaft	20 mm	2.4 mH/Phase	0.026 Nm	5	0.6 A/Phase	2.9 x 10⁻⁷	0.07 kg	7 Ω/Phase	4.2 V DC
PKP Series stepper motor, 2-Phase, 20mm frame, 5 or 6 leads, double shaft Art: PKP214U06B Copied	Double Shaft	20 mm	2.4 mH/Phase	0.026 Nm	5	0.6 A/Phase	2.9 x 10⁻⁷	0.07 kg	7 Ω/Phase	4.2 V DC
PKP Series stepper motor, 2-Phase, 28mm frame, 5 or 6 leads, single shaft Art: PKP223U09A2 Copied	Single Shaft	28 mm	1.44 mH/Phase	0.075 Nm	6	0.95 A/Phase	9 x 10⁻⁷	0.11 kg	3.11 Ω/Phase	2.95 V DC
PKP Series stepper motor, 2-Phase, 28mm frame, 5 or 6 leads, double shaft Art: PKP223U09B2 Copied	Double Shaft	28 mm	1.44 mH/Phase	0.075 Nm	6	0.95 A/Phase	9 x 10⁻⁷	0.11 kg	3.11 Ω/Phase	2.95 V DC
PKP Series stepper motor, 2-Phase, 28mm frame, 5 or 6 leads, single shaft Art: PKP225U09A2 Copied	Single Shaft	28 mm	2.11 mH/Phase	0.135 Nm	6	0.95 A/Phase	18 x 10⁻⁷	0.2 kg	4.6 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 28mm frame, 5 or 6 leads, double shaft Art: PKP225U09B2 Copied	Double Shaft	28 mm	2.11 mH/Phase	0.135 Nm	6	0.95 A/Phase	18 x 10⁻⁷	0.2 kg	4.6 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 35mm frame, 5 or 6 leads, single shaft Art: PKP233U12A Copied	Single Shaft	35 mm	1.4 mH/Phase	0.16 Nm	6	1.2 A/Phase	24 x 10⁻⁷	0.18 kg	2.7 Ω/Phase	3.24 V DC
PKP Series stepper motor, 2-Phase, 35mm frame, 5 or 6 leads, double shaft Art: PKP233U12B Copied	Double Shaft	35 mm	1.4 mH/Phase	0.16 Nm	6	1.2 A/Phase	24 x 10⁻⁷	0.18 kg	2.7 Ω/Phase	3.24 V DC
PKP Series stepper motor, 2-Phase, 35mm frame, 5 or 6 leads, single shaft Art: PKP235U12A Copied	Single Shaft	35 mm	2 mH/Phase	0.3 Nm	6	1.2 A/Phase	50 x 10⁻⁷	0.285 kg	3.4 Ω/Phase	4.08 V DC
PKP Series stepper motor, 2-Phase, 35mm frame, 5 or 6 leads, double shaft Art: PKP235U12B Copied	Double Shaft	35 mm	2 mH/Phase	0.3 Nm	6	1.2 A/Phase	50 x 10⁻⁷	0.285 kg	3.4 Ω/Phase	4.08 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U04A Copied	Single Shaft	42 mm	33 mH/Phase	0.25 Nm	6	0.4 A/Phase	36 x 10⁻⁷	0.25 kg	30 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U04B Copied	Double Shaft	42 mm	33 mH/Phase	0.25 Nm	6	0.4 A/Phase	36 x 10⁻⁷	0.25 kg	30 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U06A Copied	Single Shaft	42 mm	12.4 mH/Phase	0.25 Nm	6	0.6 A/Phase	36 x 10⁻⁷	0.25 kg	11 Ω/Phase	6.6 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U06B Copied	Double Shaft	42 mm	12.4 mH/Phase	0.25 Nm	6	0.6 A/Phase	36 x 10⁻⁷	0.25 kg	11 Ω/Phase	6.6 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U08A2 Copied	Single Shaft	42 mm	5.3 mH/Phase	0.26 Nm	5	0.8 A/Phase	36 x 10⁻⁷	0.23 kg	6.6 Ω/Phase	5.3 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U08B2 Copied	Double Shaft	42 mm	5.3 mH/Phase	0.26 Nm	5	0.8 A/Phase	36 x 10⁻⁷	0.23 kg	6.6 Ω/Phase	0.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U09A2 Copied	Single Shaft	42 mm	3.7 mH/Phase	0.26 Nm	5	0.95 A/Phase	36 x 10⁻⁷	0.23 kg	4.7 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U09B2 Copied	Double Shaft	42 mm	3.7 mH/Phase	0.26 Nm	5	0.95 A/Phase	36 x 10⁻⁷	0.23 kg	4.7 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U09A Copied	Single Shaft	42 mm	5 mH/Phase	0.25 Nm	6	0.95 A/Phase	36 x 10⁻⁷	0.25 kg	4.7 Ω/Phase	4.47 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U09B Copied	Double Shaft	42 mm	5 mH/Phase	0.25 Nm	6	0.95 A/Phase	36 x 10⁻⁷	0.25 kg	4.7 Ω/Phase	4.47 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP243U12A2 Copied	Single Shaft	42 mm	2.4 mH/Phase	0.26 Nm	5	1.2 A/Phase	36 x 10⁻⁷	0.23 kg	2.7 Ω/Phase	3.2 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP243U12B2 Copied	Double Shaft	42 mm	2.4 mH/Phase	0.26 Nm	5	1.2 A/Phase	36 x 10⁻⁷	0.23 kg	2.7 Ω/Phase	3.2 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP244U04A Copied	Single Shaft	42 mm	28.6 mH/Phase	0.36 Nm	6	0.4 A/Phase	57 x 10⁻⁷	0.3 kg	30 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP244U04B Copied	Double Shaft	42 mm	28.6 mH/Phase	0.36 Nm	6	0.4 A/Phase	57 x 10⁻⁷	0.3 kg	30 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP244U08A2 Copied	Single Shaft	42 mm	8.4 mH/Phase	0.39 Nm	5	0.8 A/Phase	54 x 10⁻⁷	0.3 kg	8.9 Ω/Phase	7.1 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP244U08B2 Copied	Double Shaft	42 mm	8.4 mH/Phase	0.39 Nm	5	0.8 A/Phase	54 x 10⁻⁷	0.3 kg	8.9 Ω/Phase	7.1 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP244U08A Copied	Single Shaft	42 mm	7.6 mH/Phase	0.36 Nm	6	0.8 A/Phase	57 x 10⁻⁷	0.3 kg	7.2 Ω/Phase	5.76 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP244U08B Copied	Double Shaft	42 mm	7.6 mH/Phase	0.36 Nm	6	0.8 A/Phase	57 x 10⁻⁷	0.3 kg	7.2 Ω/Phase	5.76 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP244U12A2 Copied	Single Shaft	42 mm	3.7 mH/Phase	0.39 Nm	5	1.2 A/Phase	54 x 10⁻⁷	0.3 kg	4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP244U12B2 Copied	Double Shaft	42 mm	3.7 mH/Phase	0.39 Nm	5	1.2 A/Phase	54 x 10⁻⁷	0.3 kg	4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP244U12A Copied	Single Shaft	42 mm	3.9 mH/Phase	0.39 Nm	6	1.2 A/Phase	57 x 10⁻⁷	0.3 kg	4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP244U12B Copied	Double Shaft	42 mm	3.9 mH/Phase	0.39 Nm	6	1.2 A/Phase	57 x 10⁻⁷	0.3 kg	4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP245U05A Copied	Single Shaft	42 mm	33 mH/Phase	0.45 Nm	6	0.5 A/Phase	85 x 10⁻⁷	0.3 kg	24 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP245U05B Copied	Double Shaft	42 mm	33 mH/Phase	0.45 Nm	6	0.5 A/Phase	85 x 10⁻⁷	0.3 kg	24 Ω/Phase	12 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP245U08A2 Copied	Single Shaft	42 mm	8.3 mH/Phase	0.49 Nm	5	0.8 A/Phase	73 x 10⁻⁷	0.37 kg	8 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP245U08B2 Copied	Double Shaft	42 mm	8.3 mH/Phase	0.49 Nm	5	0.8 A/Phase	73 x 10⁻⁷	0.37 kg	8 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP245U08A Copied	Single Shaft	42 mm	11.3 mH/Phase	0.45 Nm	6	0.8 A/Phase	83 x 10⁻⁷	0.39 kg	8 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP245U08B Copied	Double Shaft	42 mm	11.3 mH/Phase	0.45 Nm	6	0.8 A/Phase	83 x 10⁻⁷	0.39 kg	8 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP245U12A2 Copied	Single Shaft	42 mm	3.7 mH/Phase	0.49 Nm	5	1.2 A/Phase	73 x 10⁻⁷	0.37 kg	3.2 Ω/Phase	3.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP245U12B2 Copied	Double Shaft	42 mm	3.7 mH/Phase	0.49 Nm	5	1.2 A/Phase	73 x 10⁻⁷	0.37 kg	3.2 Ω/Phase	3.8 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP245U12A Copied	Single Shaft	42 mm	5 mH/Phase	0.45 Nm	6	1.2 A/Phase	83 x 10⁻⁷	0.39 kg	3.8 Ω/Phase	4.56 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP245U12B Copied	Double Shaft	42 mm	5 mH/Phase	0.45 Nm	6	1.2 A/Phase	83 x 10⁻⁷	0.39 kg	3.8 Ω/Phase	4.56 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP246U12A2 Copied	Single Shaft	42 mm	6 mH/Phase	0.75 Nm	5	1.2 A/Phase	110 x 10⁻⁷	0.5 kg	5.1 Ω/Phase	6.1 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP246U12B2 Copied	Double Shaft	42 mm	6 mH/Phase	0.75 Nm	5	1.2 A/Phase	110 x 10⁻⁷	0.5 kg	5.1 Ω/Phase	6.1 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP246U12A Copied	Single Shaft	42 mm	6.5 mH/Phase	0.75 Nm	6	1.2 A/Phase	114 x 10⁻⁷	0.5 kg	6 Ω/Phase	7.2 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP246U12B Copied	Double Shaft	42 mm	6.5 mH/Phase	0.75 Nm	6	1.2 A/Phase	114 x 10⁻⁷	0.5 kg	6 Ω/Phase	7.2 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, single shaft Art: PKP246U16A2 Copied	Single Shaft	42 mm	3.3 mH/Phase	0.75 Nm	5	1.6 A/Phase	110 x 10⁻⁷	0.5 kg	2.8 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 42mm frame, 5 or 6 leads, double shaft Art: PKP246U16B2 Copied	Double Shaft	42 mm	3.3 mH/Phase	0.75 Nm	5	1.6 A/Phase	110 x 10⁻⁷	0.5 kg	2.8 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP264U10A2 Copied	Single Shaft	56.4 mm	6 mH/Phase	0.58 Nm	5	1 A/Phase	140 x 10⁻⁷	0.45 kg	4.4 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP264U10B2 Copied	Double Shaft	56.4 mm	6 mH/Phase	0.58 Nm	5	1 A/Phase	140 x 10⁻⁷	0.45 kg	4.4 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP264U10A Copied	Single Shaft	56.4 mm	7.2 mH/Phase	0.51 Nm	6	1 A/Phase	120 x 10⁻⁷	0.46 kg	5.87 Ω/Phase	5.87 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP264U10B Copied	Double Shaft	56.4 mm	7.2 mH/Phase	0.51 Nm	6	1 A/Phase	120 x 10⁻⁷	0.46 kg	5.87 Ω/Phase	5.87 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP264U20A2 Copied	Single Shaft	56.4 mm	1.5 mH/Phase	0.58 Nm	5	2 A/Phase	140 x 10⁻⁷	0.45 kg	1.1 Ω/Phase	2.2 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP264U20B2 Copied	Double Shaft	56.4 mm	1.5 mH/Phase	0.58 Nm	5	2 A/Phase	140 x 10⁻⁷	0.45 kg	1.1 Ω/Phase	2.2 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP264U20A Copied	Single Shaft	56.4 mm	1.8 mH/Phase	0.51 Nm	6	2 A/Phase	120 x 10⁻⁷	0.46 kg	1.45 Ω/Phase	2.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP264U20B Copied	Double Shaft	56.4 mm	1.8 mH/Phase	0.51 Nm	6	2 A/Phase	120 x 10⁻⁷	0.46 kg	1.45 Ω/Phase	2.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP264U30A Copied	Single Shaft	56.4 mm	0.8 mH/Phase	0.51 Nm	6	3 A/Phase	120 x 10⁻⁷	0.46 kg	0.65 Ω/Phase	1.95 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP264U30B Copied	Double Shaft	56.4 mm	0.8 mH/Phase	0.51 Nm	6	3 A/Phase	120 x 10⁻⁷	0.46 kg	0.65 Ω/Phase	1.95 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP266U10A2 Copied	Single Shaft	56.4 mm	11.6 mH/Phase	1.1 Nm	5	1 A/Phase	270 x 10⁻⁷	0.7 kg	6.9 Ω/Phase	6.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP266U10B2 Copied	Double Shaft	56.4 mm	11.6 mH/Phase	1.1 Nm	5	1 A/Phase	270 x 10⁻⁷	0.7 kg	6.9 Ω/Phase	6.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP266U10A Copied	Single Shaft	56.4 mm	11.6 mH/Phase	1.1 Nm	6	1 A/Phase	290 x 10⁻⁷	0.73 kg	8.1 Ω/Phase	8.1 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP266U10B Copied	Double Shaft	56.4 mm	11.6 mH/Phase	1.1 Nm	6	1 A/Phase	290 x 10⁻⁷	0.73 kg	8.1 Ω/Phase	8.1 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP266U20A2 Copied	Single Shaft	56.4 mm	2.9 mH/Phase	1.1 Nm	5	2 A/Phase	270 x 10⁻⁷	0.7 kg	1.7 Ω/Phase	3.4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP266U20B2 Copied	Double Shaft	56.4 mm	2.9 mH/Phase	1.1 Nm	5	2 A/Phase	270 x 10⁻⁷	0.7 kg	1.7 Ω/Phase	3.4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP266U20A Copied	Single Shaft	56.4 mm	2.9 mH/Phase	1.1 Nm	6	2 A/Phase	290 x 10⁻⁷	0.73 kg	2 Ω/Phase	4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP266U20B Copied	Double Shaft	56.4 mm	2.9 mH/Phase	1.1 Nm	6	2 A/Phase	290 x 10⁻⁷	0.73 kg	2 Ω/Phase	4 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP266U30A Copied	Single Shaft	56.4 mm	1.33 mH/Phase	1.1 Nm	6	3 A/Phase	290 x 10⁻⁷	0.73 kg	0.92 Ω/Phase	2.76 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP266U30B Copied	Double Shaft	56.4 mm	1.33 mH/Phase	1.1 Nm	6	3 A/Phase	290 x 10⁻⁷	0.73 kg	0.92 Ω/Phase	2.76 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP268U10A2 Copied	Single Shaft	56.4 mm	18.4 mH/Phase	2 Nm	5	1 A/Phase	500 x 10⁻⁷	1.1 kg	9.9 Ω/Phase	9.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP268U10B2 Copied	Double Shaft	56.4 mm	18.4 mH/Phase	2 Nm	5	1 A/Phase	500 x 10⁻⁷	1.1 kg	9.9 Ω/Phase	9.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP268U10A Copied	Single Shaft	56.4 mm	17.6 mH/Phase	1.75 Nm	6	1 A/Phase	490 x 10⁻⁷	1.1 kg	9.32 Ω/Phase	9.32 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP268U10B Copied	Double Shaft	56.4 mm	17.6 mH/Phase	1.75 Nm	6	1 A/Phase	490 x 10⁻⁷	1.1 kg	9.32 Ω/Phase	9.32 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP268U20A2 Copied	Single Shaft	56.4 mm	4.6 mH/Phase	2 Nm	5	2 A/Phase	500 x 10⁻⁷	1.1 kg	2.4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP268U20B2 Copied	Double Shaft	56.4 mm	4.6 mH/Phase	2 Nm	5	2 A/Phase	500 x 10⁻⁷	1.1 kg	2.4 Ω/Phase	4.8 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP268U20A Copied	Single Shaft	56.4 mm	4.4 mH/Phase	1.75 Nm	6	2 A/Phase	490 x 10⁻⁷	1.1 kg	2.45 Ω/Phase	4.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP268U20B Copied	Double Shaft	56.4 mm	4.4 mH/Phase	1.75 Nm	6	2 A/Phase	490 x 10⁻⁷	1.1 kg	2.45 Ω/Phase	4.9 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, single shaft Art: PKP268U30A Copied	Single Shaft	56.4 mm	1.96 mH/Phase	1.75 Nm	6	3 A/Phase	490 x 10⁻⁷	1.1 kg	1.05 Ω/Phase	3.15 V DC
PKP Series stepper motor, 2-Phase, 56.4mm frame, 5 or 6 leads, double shaft Art: PKP268U30B Copied	Double Shaft	56.4 mm	1.96 mH/Phase	1.75 Nm	6	3 A/Phase	490 x 10⁻⁷	1.1 kg	1.05 Ω/Phase	3.15 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, single shaft Art: PK264JA Copied	Single Shaft	60 mm	1.8 mH/Phase	0.75 Nm	6	2 A/Phase	280 x 10⁻⁷	0.6 kg	1.46 Ω/Phase	2.9 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, double shaft Art: PK264JB Copied	Double Shaft	60 mm	1.8 mH/Phase	0.75 Nm	6	2 A/Phase	280 x 10⁻⁷	0.6 kg	1.46 Ω/Phase	2.9 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, single shaft Art: PK266JA Copied	Single Shaft	60 mm	3.05 mH/Phase	1.35 Nm	6	2 A/Phase	450 x 10⁻⁷	0.83 kg	2 Ω/Phase	4 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, double shaft Art: PK266JB Copied	Double Shaft	60 mm	3.05 mH/Phase	1.35 Nm	6	2 A/Phase	450 x 10⁻⁷	0.83 kg	2 Ω/Phase	4 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, single shaft Art: PK267JA Copied	Single Shaft	60 mm	3.54 mH/Phase	1.7 Nm	6	2 A/Phase	570 x 10⁻⁷	1.02 kg	2.4 Ω/Phase	4.8 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, double shaft Art: PK267JB Copied	Double Shaft	60 mm	3.54 mH/Phase	1.7 Nm	6	2 A/Phase	570 x 10⁻⁷	1.02 kg	2.4 Ω/Phase	4.8 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, single shaft Art: PK269JA Copied	Single Shaft	60 mm	5.7 mH/Phase	2.2 Nm	6	2 A/Phase	900 x 10⁻⁷	1.43 kg	2.98 Ω/Phase	6 V DC
PK Series stepper motor, 2-Phase, 60mm frame, 5 or 6 leads, double shaft Art: PK269JB Copied	Double Shaft	60 mm	5.7 mH/Phase	2.2 Nm	6	2 A/Phase	900 x 10⁻⁷	1.43 kg	2.98 Ω/Phase	6 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP296U20A Copied	Single Shaft	85 mm	7.8 mH/Phase	2.6 Nm	6	2 A/Phase	1100 x 10⁻⁷	1.8 kg	2.2 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP296U20B Copied	Double Shaft	85 mm	7.8 mH/Phase	2.6 Nm	6	2 A/Phase	1100 x 10⁻⁷	1.8 kg	2.2 Ω/Phase	4.4 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP296U30A Copied	Single Shaft	85 mm	3.5 mH/Phase	2.6 Nm	6	3 A/Phase	1100 x 10⁻⁷	1.8 kg	1 Ω/Phase	3 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP296U30B Copied	Double Shaft	85 mm	3.5 mH/Phase	2.6 Nm	6	3 A/Phase	1100 x 10⁻⁷	1.8 kg	1 Ω/Phase	3 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP296U45A Copied	Single Shaft	85 mm	1.6 mH/Phase	2.6 Nm	6	4.5 A/Phase	1100 x 10⁻⁷	1.8 kg	0.45 Ω/Phase	2 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP296U45B Copied	Double Shaft	85 mm	1.6 mH/Phase	2.6 Nm	6	4.5 A/Phase	1100 x 10⁻⁷	1.8 kg	0.45 Ω/Phase	2 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP299U20A Copied	Single Shaft	85 mm	13.2 mH/Phase	5 Nm	6	2 A/Phase	2200 x 10⁻⁷	2.9 kg	3.2 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP299U20B Copied	Double Shaft	85 mm	13.2 mH/Phase	5 Nm	6	2 A/Phase	2200 x 10⁻⁷	2.9 kg	3.2 Ω/Phase	6.4 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP299U30A Copied	Single Shaft	85 mm	6 mH/Phase	5 Nm	6	3 A/Phase	2200 x 10⁻⁷	2.9 kg	1.5 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP299U30B Copied	Double Shaft	85 mm	6 mH/Phase	5 Nm	6	3 A/Phase	2200 x 10⁻⁷	2.9 kg	1.5 Ω/Phase	4.5 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP299U45A Copied	Single Shaft	85 mm	2.6 mH/Phase	5 Nm	6	4.5 A/Phase	2200 x 10⁻⁷	2.9 kg	0.63 Ω/Phase	2.8 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP299U45B Copied	Double Shaft	85 mm	2.6 mH/Phase	5 Nm	6	4.5 A/Phase	2200 x 10⁻⁷	2.9 kg	0.63 Ω/Phase	2.8 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP2913U20A Copied	Single Shaft	85 mm	18 mH/Phase	7.3 Nm	6	2 A/Phase	3400 x 10⁻⁷	4 kg	3.8 Ω/Phase	7.6 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP2913U20B Copied	Double Shaft	85 mm	18 mH/Phase	7.3 Nm	6	2 A/Phase	3400 x 10⁻⁷	4 kg	3.8 Ω/Phase	7.6 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, single shaft Art: PKP2913U40A Copied	Single Shaft	85 mm	4.4 mH/Phase	7.3 Nm	6	4 A/Phase	3400 x 10⁻⁷	4 kg	0.94 Ω/Phase	3.8 V DC
PKP Series stepper motor, 2-Phase, 85mm frame, 5 or 6 leads, double shaft Art: PKP2913U40B Copied	Double Shaft	85 mm	4.4 mH/Phase	7.3 Nm	6	4 A/Phase	3400 x 10⁻⁷	4 kg	0.94 Ω/Phase	3.8 V DC
