ZEBRA TECHNOLOGIES

Zebra VS70 Smart Camera

Every day, production lines strive to achieve consistent product quality and meet quotas. Success requires a reliable process at every stage of production.



Now manufacturers can do all quality checks and machine vision measurements with the VS70 smart camera.



The adaptable VS70 is built for use in the most complex processes and challenging environments. Whether you need a wide-angle lens to capture large parts, or a zoom lens to inspect something far away, the VS70 can do it all by allowing the user to use any C-mount lens. If you need to upgrade your vision solution, you can easily add more advanced functions by purchasing a software license without buying new hardware.

Read more
  • Complete Customization with C-Mount Lens Support: The VS70 supports any C-mount external lens, allowing users to select specialized lenses for unique inspection needs
  • Zebra Aurora Software Integration: Managed through Zebra Aurora, the VS70 provides a unified interface for setup, deployment, and operation, suitable for users of all experience levels
  • Power Over Ethernet (PoE) Capability: PoE simplifies installation by powering the device over the network cable, reducing the need for separate power sources and making deployment easier
  • Zebra Aurora Software Integration: Managed through Zebra Aurora, the VS70 provides a unified interface for setup, deployment, and operation, suitable for users of all experience levels with features like built-in tutorials and an intuitive interface
  • ImagePerfect+ Technology for Precise Inspections: The VS70 captures up to 16 images in one trigger, each with unique settings, ensuring high-quality images for accurate inspections even in complex lighting or object positioning scenarios​

Selected variant

Available in several variants

Selected variant

Technical data

Interface out Dual Ethernet (1 POE), Serial, USB & Industrial Protocols
Lens Barrel C-Mount
Resolution 2.3 MP
Size 63.0 x 95.0 x 65.0
Software performance STANDARD MV TOOLSET
Type of scanner Smart Camera

Product description

Every day, production lines strive to achieve consistent product quality and meet quotas. Success requires a reliable process at every stage of production.



Now manufacturers can do all quality checks and machine vision measurements with the VS70 smart camera.



The adaptable VS70 is built for use in the most complex processes and challenging environments. Whether you need a wide-angle lens to capture large parts, or a zoom lens to inspect something far away, the VS70 can do it all by allowing the user to use any C-mount lens. If you need to upgrade your vision solution, you can easily add more advanced functions by purchasing a software license without buying new hardware.

Accessories

Related products

Related

Parts Resolution Software performance Price
2.3 MP
STANDARD MV TOOLSET
2.3 MP
Sensor Toolset W/ Fast 2D Decode
2.3 MP
Sensor Toolset
5.1 MP
STANDARD MV TOOLSET
5.1 MP
Sensor Toolset W/ Fast 2D Decode
