SPECIM
FX17
FX17 Series
The Specim FX17 is a hyperspectral NIR camera for industrial material identification and quality control with 224 spectral bands in the range of 900-1700 nm.
Specim FX17 – Hyperspectral NIR Camera The Specim FX17 is a hyperspectral line scanner camera for industrial and laboratory environments, operating in the near-infrared (NIR) range of 900-1700 nm. The camera is optimized for applications that require precise material identification beyond the limit of visible light. With an InGaAs sensor, TEC cooling and SNR of 1000:1, the FX17 delivers high-quality spectral data with 640 spatial pixels and 224 freely selectable spectral bands – ideal for food and feed quality, waste sorting, recycling and moisture measurement. |
- NIR 900–1700 nm with 224 freely selectable spectral bands
- Up to 670 FPS, 640 spatial pixels, 12-bit dynamics, SNR 1000:1
- Built-in AIE with uniform spectral calibration, smile/keystone correction
- CameraLink or GigE Vision, GenICam compatible, 12 V DC
- CE, RoHS, IP52, TEC cooled InGaAs sensor, operating temperature +5 to +40°C
Selected variant
Technical data
| 3612_Pixel size (µm) | 18,7 |
|---|---|
| Approvals | CE, RoHS |
| Fan | No |
| Frame rate max | 670 fps |
| Height | 85 mm |
| Input voltage | 12 V DC (±10%) |
| IP class | IP52 |
| Length | 150 mm |
| Lens barrel | Custom mount |
| Line speed max | 0.7 kHz |
| Operating humidity | 5–95% (icke-kondenserande) |
| Operating temperature | +5 … +40°C (icke-kondenserande) |
| Pixel size min | 18.7 µm |
|---|---|
| Power consumption | 24 W |
| Sensor length | 12 mm |
| Storage temperature | -20 … +50°C (icke-kondenserande) |
| Supply voltage | 12 V |
| Supply voltage dc max | 13.2 V DC |
| Supply voltage dc min | 10.8 V DC |
| User interface | CameraLink |
| Wavelength | 900–1700 nm |
| Weight | 1.56 kg |
| Width | 75 mm |
Downloads
Product description
The Specim FX17 is a hyperspectral NIR camera for industrial material identification and quality control with 224 spectral bands in the range of 900-1700 nm.
Specim FX17 – Hyperspectral NIR Camera The Specim FX17 is a hyperspectral line scanner camera for industrial and laboratory environments, operating in the near-infrared (NIR) range of 900-1700 nm. The camera is optimized for applications that require precise material identification beyond the limit of visible light. With an InGaAs sensor, TEC cooling and SNR of 1000:1, the FX17 delivers high-quality spectral data with 640 spatial pixels and 224 freely selectable spectral bands – ideal for food and feed quality, waste sorting, recycling and moisture measurement. |
