Chrome Modular Power Supply 24VDC 24VDC, 0.42-3.8A, 10-92W DRC-24V100W1AZ | OEM Automatic Ltd

Technical data / Documents

Accessories & Related products

Selected variant

Technical data

Input data
Input voltage ac	100-240 V
Input voltage ac min	90 V AC
Input voltage ac max	264 V AC
Input voltage dc	125-375 V
Input voltage dc min	125 V DC
Input voltage dc max	375 V DC
Inrush current at 120 V ac typical	30 A
Inrush current at 230 V ac typical	60 A
Output data
Output voltage	24 V DC
Output voltage min	22 V DC
Output voltage max	24 V DC
Output current	3.8 A
Power	91.2 W
Efficiency / Lifetime / MTBF
Efficiency	89 %
Dimensions
Width	89.9 mm

Invisible Heading
Height	91 mm
Depth	55.6 mm
Weight	0.35 kg
Other
Approvals	CB, CE, NEC Class 2, TÜV, UL
Hold time at 120 V ac, typical full load	10 ms
Hold time at 230 V ac, typical full load	60 ms
IP class	IP20
Clamp type	Screw
Material protection	Plastic
Supply frequency	50-60 Hz
Power consumption 120 V ac	2.2 A
Power consumption 230 V ac	1 A
Temperature min without derating	-25 °C
Temperature max without derating	55 °C

Downloads

Measurements and connections

Accessories

Related

Signal lights auer

Signal Lights For You

New signal lights from Auer Signal are now available! The first products to be launched in this series are the Smart Dot 50 in the Basic and Standard versions, as well as the Smart Indicator 50 in the Basic version.

Kubler slip rings encoders

Blog Product news

Optimise your production line with sensors

Optimise your production line with encoders, inclinometers, displays and slip rings

contaclip kds sr90

Every angle covered with 90 degree cable entry system

Engineers and technicians are seeking solutions that streamline assembly whilst maintaining high levels of protection and flexibility. KDS-SR90 angled screw frames and inlays bring a new level of efficiency to cable routing with a unique 90° entry design.

crouzet millenium slim on limited time discount

The smallest logic controller ever on limited time discount

The smallest logic controller by Crouzet is now 20% off for a limited time only! A powerhouse packed into just 17.5mm! Efficiency, adaptability, and seamless integration with free software.

11 questions to get the right signalling device with Auer Signal & OEM Automatic

11 questions to get the right signalling device – a whitepaper

Do you require signalling devices and beacons in your production process? Download our latest whitepaper!

bespoke solutions electricity meter control boxes

Control Box Assembly for Industrial Electricity Metering - A case study

Here, our customer requires control boxes for electricity metering systems. We leveraged our expertise to deliver easy-to-install, ready-to-use assemblies. We look forward to creating more of these bespoke control boxes for our customer.

	Parts	Inrush current at 120 V ac typical	Inrush current at 230 V ac typical	Output voltage min	Output voltage max	Output current	Power	Efficiency	Width	Weight	Hold time at 120 V ac, typical full load	Power consumption 120 V ac	Power consumption 230 V ac	Price
	Power Supply Chrome 24VDC 10W 0.42A Art: DRC-24V10W1AZ Copied	15 A	30 A	24 V DC	24 V DC	0.42 A	10 W	80 %	18 mm	0.065 kg	10 ms	0.3 A	0.2 A
	Art: DRC-24V10W1HZ Copied	15 A	30 A	24 V DC	24 V DC	0.42 A	10 W	80 %	18 mm	0.065 kg	10 ms	0.3 A	0.2 A
	Art: DRC-24V30W1AZ Copied	25 A	50 A	23.52 V DC	24.48 V DC	1.25 A	30 W	87 %	53 mm	0.14 kg	25 ms	0.8 A	0.6 A
	Power Supply Chrome 24VDC 60W 2.5A Art: DRC-24V60W1AZ Copied	30 A	60 A	24 V DC	28 V DC	2.5 A	60 W	88 %	71 mm	0.22 kg	16 ms	1.5 A	1 A
	Art: DRC-24V100W1AZ Copied	30 A	60 A	22 V DC	24 V DC	3.8 A	91.2 W	89 %	89.9 mm	0.35 kg	10 ms	2.2 A	1 A
