| Additional functions | Conversion of any measured value into current or voltage analog signal. Storage of minimal and maximal values for all measured quantites. 21-point rescaling for the measured value (does not apply to N30P and N27P). Password protection. Programmable current and voltage transformer ratio (applies to N27P and N30P). |
|---|---|
| Digital interface | RS-485 Modbus Slave - Option |
| Dimensions | 96 x 48 x 93 mm |
| Display | Yes |
| Input type | d.c. current 6 A, d.c. voltage 600 V |
| IP class | IP65 |
| Mounting | Panel mount |
| Number of digits | 5 |
|---|---|
| Number of rows | 1 Â |
| Outputs | 2 relays (NO) |
| Supply voltage | 85-253V ac/dc |
| Temperature operational max | 55 °C |
| Weight | 0.2 kg |
Please refer to the image below for ordering information.
Have you ever wondered if there's any difference between cable coils and cable reels?
Our cable experts take you through the advantages of using cable coils.
What tri-rated cable are you currently using? Does the product or service you receive leave you wanting more? It’s time to ask the question. Because now, you’ve got options.
This innovative push-in connection system enables time savings of up to 50%, whether you're wiring control panels or managing complex installations
Solar energy has become a pillar of the global energy transition. The experts at OEM Automatic have broken down the role of photovoltaic fuses and their contribution to solar systems, as well as, how to choose the right solution for you.
Ultra fast-acting fuse links engineered specifically to shield delicate semiconductor devices.
Do you need reliable protection for measuring and control equipment? DEHN YellowLine delivers voltage surge protection tailored for building, measuring, and control systems
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Parts | Outputs | Supply voltage | Price | ||
|---|---|---|---|---|---|
Panel Meter, 2x OC Outputs, 85-253V ac
Art:
N30H10XX
Copied
|
2 relays (NO)
|
85-253V ac/dc
|
|
||
|
Panel Meter, 2 x OC Outputs, RS-485, 1A Ouput 85-253V ac
Art:
N30H11XX
Copied
|
analog, RS485, 2 relays
|
85-253V ac/dc
|
|
||
|
Panel Meter, 4 x OC Outputs, RS-485, 1A Ouput, 85-253V ac
Art:
N30H12XX
Copied
|
analog,RS485, 4 relays
|
85-253V ac/dc
|
|
||
|
Panel Meter, 2x OC Outputs, 20-60V dc
Art:
N30H20XX
Copied
|
2 relays (NO)
|
20-40V ac/dc
|
|
||
|
Panel Meter, 2 x OC Outputs, RS-485, 1A Ouput 20-60V dc
Art:
N30H21XX
Copied
|
analog, RS485, 2 relays
|
20-40V ac/dc
|
|
||
|
Panel Meter, 4 x OC Outputs, RS-485, 1A Ouput, 20-60V dc
Art:
N30H22XX
Copied
|
analog,RS485, 4 relays
|
20-40V ac/dc
|
|
Select a variant in the list
