FLEXA
ROHRflex® PA 12 protective conduit
ROHRflex PA 12 provides high flexibility needed in applications such as robot installations in- and outdoors. Both internally and externally corrugated. Good oil resistance.
Â
|
Supplied in full packages, also available in orange and grey colors.
- Very flexible
- Resistant against continuous bending
- Halogen-free
Selected variant
Technical data
| Approvals | CE, VDE |
|---|---|
| Bending radius ±10% dynamic | 35 |
| Bending radius -10% static | 13 |
| Colour | Black |
| Fire rating | UL94-V2 |
| Hose dimension AD | 10 |
| Inner dimensions | 6.5 mm |
| Material | Polyamide |
| Outer dimensions | 10 mm |
|---|---|
| Pack size | 50 m |
| Temperature operational max | 100 °C |
| Temperature operational min | -50 °C |
| Type | ROHRFLEX -PA12 |
| Weight / m | 0.2 |
Downloads
Product description
ROHRflex PA 12 provides high flexibility needed in applications such as robot installations in- and outdoors. Both internally and externally corrugated. Good oil resistance.
Â
|
Supplied in full packages, also available in orange and grey colors.
